Airtac HLSL Precision Slide Table Cylinder HLSL12X100SBS
The AirTAC Airtac HLSL Precision Slide Table Cylinder HLSL12X100SBS is a genuine HLS slide-table cylinder, 12 mm bore: a double-acting dual-rod air cylinder integrated with a cross-roller guide so the table travels straight with high rigidity and low deflection. It delivers about 85 N of push at 0.5 MPa. This is the symmetrical version. A floating joint spares the rod from side torque; the magnet is fitted as standard.
- TypeSlide-table, double acting
- Guidecross-roller guide
- Bore12 mm
- Push thrust @0.5 MPa85 N
- Operating pressure0.15 - 0.7 MPa (22 - 100 psi)
- Port sizeM5x0.8
- CushionBumper (+ shock-absorber option)
- Magnet / sensorStandard; CMSH/DMSH/EMSH
- ThreadPT
About the Airtac HLSL Precision Slide Table Cylinder HLSL12X100SBS
The HLSL12X100SBS is a genuine AirTAC double-acting dual-rod slide-table cylinder integrating an air cylinder with a cross-roller linear guide. The cross-roller guide provides high precision, rigidity, and low deflection. The dual rod doubles thrust and the floating joint protects the rod from side torque. Bore 12 mm with 100 mm stroke suits longer-travel guided positioning tasks.
This is a symmetrical-body variant of the HLS series. The magnet is standard; sensor switches CMSH, DMSH, or EMSH fit the body slots. The BS adjuster adds a shock absorber at the extension side to cushion end-of-stroke impact on the extend stroke. Thread is PT. We confirm exact thrust, dimensions, and allowable load/moment from the published datasheet or on-page table on request.
Airtac HLSL Precision Slide Table Cylinder HLSL12X100SBS Technical Specifications
| Model | Airtac HLSL Precision Slide Table Cylinder HLSL12X100SBS |
|---|---|
| Type | Slide-table cylinder, double acting, dual rod |
| Series / guide | HLSL (cross-roller guide) |
| Bore | 12 mm |
| Push thrust @0.5 MPa | 85 N |
| Port size | M5x0.8 (PT thread) |
| Fluid | Air, filtered to 40 um |
|---|---|
| Operating pressure | 0.15 - 0.7 MPa (22 - 100 psi) |
| Proof pressure | 1.2 MPa (175 psi) |
| Temperature | -20 to 70 C |
| Speed range | 50 - 500 mm/s (meter-out) |
| Cushion | Bumper; shock-absorber / adjustable-stopper options |
| Magnet / sensor | Standard; CMSH, DMSH, EMSH |
Specifications follow the official AirTAC HL slide-table data. Max working pressure is 0.7 MPa. The table rides on an integrated linear guide — do not apply strong impact or large moment. Allowable load and moment are published as tables and curves, and overall dimensions vary per stroke — ask us and we confirm from the datasheet.
How to choose
The 12 mm bore gives moderate thrust for a compact guided slide; a larger bore increases push and pull. The HLS cross-roller guide is chosen when precision and rigidity are the priority. Stroke 100 mm is within the bore-12 range; the BS shock-absorber option at the extension side cushions impact when the extend stroke carries momentum. Confirm load and moment sizing from the published tables and deflection curves - contact us for verified values.
Applications
Component Placement
Positions small parts precisely along a 100 mm guided path with cross-roller rigidity and extend-side shock absorption.
Lateral Part Transfer
Shifts workpieces between stations with low deflection over the full 100 mm stroke and dual-rod thrust.
Gripper Traverse Stage
Carries a gripper assembly across the 100 mm stroke with shock-absorber cushioning at the extend end.
FAQ
What is the difference between BS and BF adjuster codes?
BS places a shock absorber at the extension side only; BF places it at the retraction side only. Both are available on HLS/HLQ bore 12 and above. Choose the side where end-of-stroke impact energy is higher.
Is the magnet optional on this slide table?
No - the magnet is standard on the entire HLSL line, denoted by the S in the model code. Sensor switches CMSH, DMSH, and EMSH mount in the magnetic-switch slots on the body.
