Airtac HLSL Precision Slide Table Cylinder HLSL12X10S
The AirTAC Airtac HLSL Precision Slide Table Cylinder HLSL12X10S is a genuine HLS slide-table cylinder, 12 mm bore: a double-acting dual-rod air cylinder integrated with a cross-roller guide so the table travels straight with high rigidity and low deflection. It delivers about 85 N of push at 0.5 MPa. This is the symmetrical version. A floating joint spares the rod from side torque; the magnet is fitted as standard.
- TypeSlide-table, double acting
- Guidecross-roller guide
- Bore12 mm
- Push thrust @0.5 MPa85 N
- Operating pressure0.15 - 0.7 MPa (22 - 100 psi)
- Port sizeM5x0.8
- CushionBumper (+ shock-absorber option)
- Magnet / sensorStandard; CMSH/DMSH/EMSH
- ThreadPT
- No minimum order. A single piece can be ordered.
- Ready in 3–5 business days. That is the time we take to process the order and hand it to the carrier. Transit time after that depends on the destination.
About the Airtac HLSL Precision Slide Table Cylinder HLSL12X10S
The HLSL12X10S is a genuine AirTAC double-acting dual-rod slide-table cylinder that integrates an air cylinder with a cross-roller linear guide. The cross-roller guide delivers high precision and rigidity with low deflection, the dual rod doubles thrust, and a floating joint protects the rod from side torque. Bore 12 mm with a short 10 mm stroke suits compact indexing and clamping tasks.
This is a symmetrical-body variant of the HLS series with basic bumper cushioning. The magnet is standard; sensor switches CMSH, DMSH, or EMSH mount in the body slots. Thread is PT. We confirm exact thrust, dimensions, and allowable load/moment from the published datasheet or on-page table on request.
Airtac HLSL Precision Slide Table Cylinder HLSL12X10S Technical Specifications
| Model | Airtac HLSL Precision Slide Table Cylinder HLSL12X10S |
|---|---|
| Type | Slide-table cylinder, double acting, dual rod |
| Series / guide | HLSL (cross-roller guide) |
| Bore | 12 mm |
| Push thrust @0.5 MPa | 85 N |
| Port size | M5x0.8 (PT thread) |
| Fluid | Air, filtered to 40 um |
|---|---|
| Operating pressure | 0.15 - 0.7 MPa (22 - 100 psi) |
| Proof pressure | 1.2 MPa (175 psi) |
| Temperature | -20 to 70 C |
| Speed range | 50 - 500 mm/s (meter-out) |
| Cushion | Bumper; shock-absorber / adjustable-stopper options |
| Magnet / sensor | Standard; CMSH, DMSH, EMSH |
Specifications follow the official AirTAC HL slide-table data. Max working pressure is 0.7 MPa. The table rides on an integrated linear guide — do not apply strong impact or large moment. Allowable load and moment are published as tables and curves, and overall dimensions vary per stroke — ask us and we confirm from the datasheet.
How to choose
The 12 mm bore provides moderate thrust for a compact guided slide; a larger bore in the same series increases push and pull. The HLS cross-roller guide is the choice when precision and rigidity are critical. Stroke 10 mm is within the bore-12 range for very short travel. This model uses basic bumper cushioning without an adjustable stopper or shock absorber. Confirm load and moment sizing from the published tables and deflection curves - contact us for verified values.
Applications
Short-Stroke Indexer
Indexes a small fixture precisely over 10 mm with cross-roller guide accuracy and dual-rod thrust.
Clamping Slide
Advances a clamp jaw 10 mm to hold a workpiece with rigid guided travel and no rod side-load.
Gripper Positioner
Positions a small gripper for a short 10 mm traverse between pick and place points in tight clearance.
FAQ
Does this HLSL12X10S model include a shock absorber or adjustable stopper?
No - the blank adjuster field means basic bumper cushioning only. Adjustable rubber stoppers (A/AS/AF) and shock absorbers (B/BS/BF) are optional on HLS/HLQ and can be specified in the model code if needed.
What load and moment can this slide table handle?
Allowable load, moment, and kinetic energy are published as tables and deflection curves in the datasheet. We confirm the exact values for your application on request - do not estimate from the bore alone.
