Airtac HLSL Precision Slide Table Cylinder HLSL12X10SAF
The AirTAC Airtac HLSL Precision Slide Table Cylinder HLSL12X10SAF is a genuine HLS slide-table cylinder, 12 mm bore: a double-acting dual-rod air cylinder integrated with a cross-roller guide so the table travels straight with high rigidity and low deflection. It delivers about 85 N of push at 0.5 MPa. This is the symmetrical version. A floating joint spares the rod from side torque; the magnet is fitted as standard.
- TypeSlide-table, double acting
- Guidecross-roller guide
- Bore12 mm
- Push thrust @0.5 MPa85 N
- Operating pressure0.15 - 0.7 MPa (22 - 100 psi)
- Port sizeM5x0.8
- CushionBumper (+ shock-absorber option)
- Magnet / sensorStandard; CMSH/DMSH/EMSH
- ThreadPT
About the Airtac HLSL Precision Slide Table Cylinder HLSL12X10SAF
The AirTAC HLSL12X10SAF is a double-acting dual-rod slide-table cylinder combining a symmetrical cross-roller linear guide with a 12mm bore, 10mm stroke air cylinder. The cross-roller guide delivers high precision and rigidity with low deflection, and the dual rod provides moderate thrust for this bore. A floating joint shields the rod from side torque for straight, smooth table travel. Adjustable rubber stoppers are fitted on the retraction side only.
This is a genuine AirTAC part with a standard sintered NdFeB magnet for position sensing; compatible sensor switches include CMSH, DMSH, and EMSH series in the body slots. We confirm thrust, dimensions, and load-moment values from the AirTAC datasheet or on-page spec table on request.
Airtac HLSL Precision Slide Table Cylinder HLSL12X10SAF Technical Specifications
| Model | Airtac HLSL Precision Slide Table Cylinder HLSL12X10SAF |
|---|---|
| Type | Slide-table cylinder, double acting, dual rod |
| Series / guide | HLSL (cross-roller guide) |
| Bore | 12 mm |
| Push thrust @0.5 MPa | 85 N |
| Port size | M5x0.8 (PT thread) |
| Fluid | Air, filtered to 40 um |
|---|---|
| Operating pressure | 0.15 - 0.7 MPa (22 - 100 psi) |
| Proof pressure | 1.2 MPa (175 psi) |
| Temperature | -20 to 70 C |
| Speed range | 50 - 500 mm/s (meter-out) |
| Cushion | Bumper; shock-absorber / adjustable-stopper options |
| Magnet / sensor | Standard; CMSH, DMSH, EMSH |
Specifications follow the official AirTAC HL slide-table data. Max working pressure is 0.7 MPa. The table rides on an integrated linear guide — do not apply strong impact or large moment. Allowable load and moment are published as tables and curves, and overall dimensions vary per stroke — ask us and we confirm from the datasheet.
How to choose
Bore 12 is chosen for moderate thrust in a compact cross-roller guide; select a larger bore if more push force is needed. The HLSL symmetrical cross-roller guide offers highest precision and rigidity among the HL sub-families. Stroke 10mm is within the bore 12 range. This model has an adjustable rubber stopper on the retraction side (code AF) with a standard bumper at the extension end. Thread is PT; port is 1/8 inch. Route allowable load and moment sizing to us - published as tables and deflection curves in the datasheet.
Applications
Gripper Traverse
Traverses a small gripper for component handling with cross-roller precision and retraction-side stopper control.
Part Eject Station
Ejects small parts on retraction with a tunable rubber stopper and guided dual-rod travel for repeatable positioning.
Compact Assembly Slide
Moves a workpiece carrier in a tight assembly cell with 10mm stroke and cross-roller straightness.
FAQ
How does the AF adjuster differ from A on this slide table?
Code AF places the adjustable rubber stopper on the retraction side only, while code A covers both extension and retraction ends. Choose AF when you need controlled cushioning at retraction but a standard bumper at extension. Code AS is the opposite - extension side only. Code B adds shock absorbers instead of rubber stoppers.
Where can I find allowable load and moment data for HLSL12?
Allowable load, moment, and table deflection are published as tables and curves in the AirTAC datasheet. We confirm these values for your specific stroke and mounting orientation on request so you can verify suitability before ordering.
