Airtac HLSL Precision Slide Table Cylinder HLSL12X10SAS
2、Pre-equipped positioning pin holes on guide rail for accurate mounting
3、Floating joint design prevents piston rod from bearing additional torsional loads
4、Dual piston rod configuration achieves double output force
5、Integrated positioning pin holes on main body for secure installation
6、Mounting screw holes provided on base surface and end faces
Category: Precision Slide Cylinder , Brand: AirTAC , Series: HLSL
AirTAC HLSL12X10SAS Precision Slide Table Cylinder Specifications
- Model: HLSL12X10SAS
- Type: Dual-axis guided precision cylinder
- Bore size: 12mm
- Stroke: 10mm (±0.5mm adjustability)
- Operating pressure: 0.05-0.7 MPa
- Max thrust: 38N (at 0.5MPa)
- Piston speed: 50-700mm/s
- Repeat positioning accuracy: ±0.01mm
- Rod material: Hardened stainless steel SCM435
- Guide rail: Linear ball bearings with 4-row structure
- Seal material: Special-grade polyurethane (PU)
- Temperature range: -10℃ to 80℃
- Lubrication: Pre-lubed (Molykote EM-30L)
- Weight: 0.52kg
- Dimensions: 80mm(L) × 40mm(W) × 32mm(H)
- Mounting: Standard M4 threaded holes (4 locations)
- Accessories: Optional magnetic sensor (D-A93)
Ultra-compact slide cylinder with integrated linear guide, achieving micron-level positioning through hardened ground shafts and precision ball recirculation system. Features anti-rotation mechanism and IP54 dust protection. The S-type suffix indicates enhanced side load capacity (up to 15N lateral force). Requires filtered air (5μm+auto drain).
- PCB component insertion machines
- Lens polishing equipment positioning stages
- Semiconductor wafer handling robots
- Micro-dispensing systems
- Optical fiber alignment devices
Operation tip:
Maintain 0.05-0.15mm clearance between stopper plates during installation.
For continuous reciprocation, limit duty cycle to 70% at max speed. Lubrication interval: 500km travel distance.
| Property | Property Value |
|---|---|
| sku | HLSL12X10SAS |
| External Stop Block Type | Front End Stroke Adjustment Screw |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20-70°C Speed Range: 50-500 mm/s |
| Port Size | M5×0.8 |
| Magnet | S-Magnetic |
| Bore Diameter | 12mm |
| Stroke | <10mm> |
