Airtac HLSL Precision Slide Table Cylinder HLSL12X10SB
$256.33
Regular price
$263.83
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
HLSL12X10SB
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
1、The integrated design of cross roller guides and cylinder ensures high strength, precision, and load-bearing capacity, delivering exceptional straightness and anti-rotation accuracy - ideal for precision assembly applications;
2、Pre-equipped positioning pin holes on guide rail for accurate mounting
3、Floating joint design prevents piston rod from bearing additional torsional loads
4、Dual piston rod configuration achieves double output force
5、Integrated positioning pin holes on main body for secure installation
6、Mounting screw holes provided on base surface and end faces
Category: Precision Slide Cylinder , Brand: AirTAC , Series: HLSL
Installation note:
For maximum accuracy, mount on Class 5 flatness surface. Use 0.3-0.5Nm torque for mounting screws.
Lubricate guide shafts weekly with ISO VG15-32 oil in high-cycle applications (>500,000 cycles/month).
2、Pre-equipped positioning pin holes on guide rail for accurate mounting
3、Floating joint design prevents piston rod from bearing additional torsional loads
4、Dual piston rod configuration achieves double output force
5、Integrated positioning pin holes on main body for secure installation
6、Mounting screw holes provided on base surface and end faces
Category: Precision Slide Cylinder , Brand: AirTAC , Series: HLSL
AirTAC HLSL12X10SB Precision Slide Table Cylinder Specifications
- Model: HLSL12X10SB
- Bore Size: 12mm
- Stroke: 10mm (±0.5mm adjustable)
- Structure: Double-axis precision guided type
- Operation: Double-acting (air pressure both directions)
- Max. Operating Pressure: 0.7 MPa
- Port Size: M5x0.8 (Rc1/8 optional)
- Cushioning: Adjustable rubber buffer
- Repeat Positioning Accuracy: ±0.01mm
- Max. Load Capacity: 10kg (vertical), 5kg (horizontal)
- Operating Temperature: -20℃ to 80℃
- Material: Aluminum alloy body, hardened steel shafts
- Seal Material: NBR (Nitrile rubber)
- Weight: 0.48kg
- Dimensions (L×W×H): 100×30×30mm (body), 130×42×42mm (full extension)
- Mounting: Standard M4 threaded holes (4x)
- Rod End: Female M3 thread
Ultra-compact linear motion solution with dual hardened guide rods ensuring ±0.01mm repeatability. Features anti-rotation design and integrated T-slot for accessory mounting. Requires filtered air (5-40μm) with 1-3% lubricating oil mist (ISO VG32 recommended).
Typical Applications:
- PCB component insertion machines
- Lens positioning in optical inspection systems
- Micro-dispensing equipment for medical devices
- Semiconductor wafer handling robots
- Precision alignment stages in photonics
Installation note:
For maximum accuracy, mount on Class 5 flatness surface. Use 0.3-0.5Nm torque for mounting screws.
Lubricate guide shafts weekly with ISO VG15-32 oil in high-cycle applications (>500,000 cycles/month).
| Property | Property Value |
|---|---|
| sku | HLSL12X10SB |
| External Stop Block Type | Double-Ended Hydraulic Shock Absorber |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20-70°C Speed Range: 50-500 mm/s |
| Port Size | M5×0.8 |
| Magnet | S-Magnetic |
| Bore Diameter | 12mm |
| Stroke | <10mm> |
