Airtac HLSL Precision Slide Table Cylinder HLSL12X10SBF
The AirTAC Airtac HLSL Precision Slide Table Cylinder HLSL12X10SBF is a genuine HLS slide-table cylinder, 12 mm bore: a double-acting dual-rod air cylinder integrated with a cross-roller guide so the table travels straight with high rigidity and low deflection. It delivers about 85 N of push at 0.5 MPa. This is the symmetrical version. A floating joint spares the rod from side torque; the magnet is fitted as standard.
- TypeSlide-table, double acting
- Guidecross-roller guide
- Bore12 mm
- Push thrust @0.5 MPa85 N
- Operating pressure0.15 - 0.7 MPa (22 - 100 psi)
- Port sizeM5x0.8
- CushionBumper (+ shock-absorber option)
- Magnet / sensorStandard; CMSH/DMSH/EMSH
- ThreadPT
About the Airtac HLSL Precision Slide Table Cylinder HLSL12X10SBF
The AirTAC HLSL12X10SBF is a symmetrical cross-roller slide-table cylinder with a 12 mm bore and 10 mm stroke. As a double-acting dual-rod design, it integrates an air cylinder with a precision cross-roller linear guide so the moving table travels straight with minimal deflection. The dual rods double the thrust for a bore of this size, and a floating joint spares the rods from side torque. A shock absorber cushions the retraction end of stroke.
This is a genuine AirTAC part with a standard magnet for position sensing via CMSH, DMSH, or EMSH switches mounted in the body slots. We confirm exact thrust, dimensions, and allowable load/moment values from the AirTAC datasheet or on-page spec table on request.
Airtac HLSL Precision Slide Table Cylinder HLSL12X10SBF Technical Specifications
| Model | Airtac HLSL Precision Slide Table Cylinder HLSL12X10SBF |
|---|---|
| Type | Slide-table cylinder, double acting, dual rod |
| Series / guide | HLSL (cross-roller guide) |
| Bore | 12 mm |
| Push thrust @0.5 MPa | 85 N |
| Port size | M5x0.8 (PT thread) |
| Fluid | Air, filtered to 40 um |
|---|---|
| Operating pressure | 0.15 - 0.7 MPa (22 - 100 psi) |
| Proof pressure | 1.2 MPa (175 psi) |
| Temperature | -20 to 70 C |
| Speed range | 50 - 500 mm/s (meter-out) |
| Cushion | Bumper; shock-absorber / adjustable-stopper options |
| Magnet / sensor | Standard; CMSH, DMSH, EMSH |
Specifications follow the official AirTAC HL slide-table data. Max working pressure is 0.7 MPa. The table rides on an integrated linear guide — do not apply strong impact or large moment. Allowable load and moment are published as tables and curves, and overall dimensions vary per stroke — ask us and we confirm from the datasheet.
How to choose
Bore 12 sits in the mid-range of the HLS family, giving moderate thrust for small-to-medium workpieces. Choose the symmetrical HLSL body when you need balanced mounting from either side. The cross-roller guide delivers the highest rigidity and precision among AirTAC slide tables. Stroke 10 mm is a short travel within the bore 12 range. This model carries a shock absorber on the retraction side only (adjuster code BF), which is available on bore 12 and larger but not on bore 6. Thread is PT (tapered). Contact us for load and moment sizing - these are published as tables and deflection curves in the datasheet.
Applications
Pick-and-Place Head
Mounts a small gripper for precise component placement with shock-absorber cushioning on the return stroke.
Parts Transfer Gate
Gates or diverts lightweight workpieces on a conveyor with controlled retraction-side deceleration.
Assembly Station Slide
Slides an assembly fixture to a home position with a shock absorber protecting the retraction stop.
FAQ
What does the BF adjuster code mean on this HLSL12X10SBF?
BF means a shock absorber is fitted on the retraction side only. The extension side uses a standard bumper. B-type adjusters are available on bore 12 and larger; they are not offered on bore 6.
How are allowable load and moment confirmed for this model?
Allowable load, moment, and kinetic energy are published as tables and deflection curves in the AirTAC datasheet. We confirm the specific values for your application on request rather than quoting a single number.
