Airtac HLSL Precision Slide Table Cylinder HLSL12X20SAF
2、Pre-equipped positioning pin holes on guide rail for accurate mounting
3、Floating joint design prevents piston rod from bearing additional torsional loads
4、Dual piston rod configuration achieves double output force
5、Integrated positioning pin holes on main body for secure installation
6、Mounting screw holes provided on base surface and end faces
Category: Precision Slide Cylinder , Brand: AirTAC , Series: HLSL
AirTAC HLSL12X20SAF Precision Slide Table Cylinder Specifications
- Model: HLSL12X20SAF
- Type: Double-acting slide table cylinder with integrated linear guide
- Bore size: 12mm
- Stroke: 20mm (±0.5mm tolerance)
- Operating pressure: 0.1–0.8 MPa
- Cushioning: Adjustable rubber buffers (both ends)
- Repeat positioning accuracy: ±0.01mm
- Guide mechanism: 2-row ball bearing structure
- Rod material: Stainless steel (SUS304)
- Body material: Anodized aluminum alloy
- Seal material: NBR + PU combination
- Temperature range: -20℃ to 80℃
- Lubrication: Pre-lubricated (Grease-free operation)
- Weight: 480g ±2%
- Dimensions: 100mm(L) × 34mm(W) × 25mm(H) (excluding mounting accessories)
- Mounting options: Through-hole (M4×0.7) and counterbore on base
- Sensor compatibility: M5 proximity sensor slots (2 channels)
Ultra-compact linear motion solution combining pneumatic actuation with precision ball-guided linear motion. Features zero-backlash design with 4-directional load capacity, ideal for vertical Z-axis applications. The dual-seal structure (wiper seal + main seal) ensures dust resistance (IP54 equivalent). Includes anti-rotation mechanism for stable tooling plate orientation.
- PCB component insertion machines
- Lens polishing equipment positioning stages
- Semiconductor wafer handling robots
- Medical device assembly with cleanroom requirements
- 3C product testing jigs
Installation note:
Requires perpendicularity within 0.05mm/m during mounting. Use only angular contact thrust bearings
when converting to electric drive. Lubricate guide rails with ISO VG32 turbine oil if operated above 60℃ continuously.
| Property | Property Value |
|---|---|
| sku | HLSL12X20SAF |
| External Stop Block Type | Rear end stroke adjusting screw |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20-70°C Speed Range: 50-500 mm/s |
| Port Size | M5×0.8 |
| Magnet | S-Magnetic |
| Bore Diameter | 12mm |
| Stroke | <20mm> |
