Airtac HLSL Precision Slide Table Cylinder HLSL12X20SAS
The AirTAC Airtac HLSL Precision Slide Table Cylinder HLSL12X20SAS is a genuine HLS slide-table cylinder, 12 mm bore: a double-acting dual-rod air cylinder integrated with a cross-roller guide so the table travels straight with high rigidity and low deflection. It delivers about 85 N of push at 0.5 MPa. This is the symmetrical version. A floating joint spares the rod from side torque; the magnet is fitted as standard.
- TypeSlide-table, double acting
- Guidecross-roller guide
- Bore12 mm
- Push thrust @0.5 MPa85 N
- Operating pressure0.15 - 0.7 MPa (22 - 100 psi)
- Port sizeM5x0.8
- CushionBumper (+ shock-absorber option)
- Magnet / sensorStandard; CMSH/DMSH/EMSH
- ThreadPT
About the Airtac HLSL Precision Slide Table Cylinder HLSL12X20SAS
The AirTAC HLSL12X20SAS is a symmetrical cross-roller slide-table cylinder with a 12 mm bore and 20 mm stroke. A dual-rod double-acting air cylinder is integrated with a high-precision cross-roller linear guide so the table travels straight with minimal deflection. The dual rods deliver moderate thrust, and a floating joint spares the rods from side torque. The AS adjuster adds an adjustable rubber stopper on the extension side for controlled end-of-stroke positioning.
This genuine AirTAC part carries a standard sintered NdFeB magnet for position sensing. Compatible sensor switches include CMSH, DMSH and EMSH series, which mount in the body's magnetic-switch slots. We confirm exact thrust, dimensions, allowable load and moment from the AirTAC datasheet or on-page spec table on request.
Airtac HLSL Precision Slide Table Cylinder HLSL12X20SAS Technical Specifications
| Model | Airtac HLSL Precision Slide Table Cylinder HLSL12X20SAS |
|---|---|
| Type | Slide-table cylinder, double acting, dual rod |
| Series / guide | HLSL (cross-roller guide) |
| Bore | 12 mm |
| Push thrust @0.5 MPa | 85 N |
| Port size | M5x0.8 (PT thread) |
| Fluid | Air, filtered to 40 um |
|---|---|
| Operating pressure | 0.15 - 0.7 MPa (22 - 100 psi) |
| Proof pressure | 1.2 MPa (175 psi) |
| Temperature | -20 to 70 C |
| Speed range | 50 - 500 mm/s (meter-out) |
| Cushion | Bumper; shock-absorber / adjustable-stopper options |
| Magnet / sensor | Standard; CMSH, DMSH, EMSH |
Specifications follow the official AirTAC HL slide-table data. Max working pressure is 0.7 MPa. The table rides on an integrated linear guide — do not apply strong impact or large moment. Allowable load and moment are published as tables and curves, and overall dimensions vary per stroke — ask us and we confirm from the datasheet.
How to choose
Choose this bore 12 model when moderate thrust and a 20 mm stroke suit your guided linear motion application. The HLSL cross-roller guide offers the highest precision and rigidity in the HL family, ideal where low deflection matters. The AS adjuster provides an adjustable rubber stopper on the extension side for fine-tuned end-of-stroke cushioning while the retraction side uses the standard bumper. Thread is PT (tapered pipe). For load and moment sizing, we reference the published AirTAC tables and deflection curves - contact us to confirm values for your mounting orientation.
Applications
Pick-and-Place Head
Mounts a small gripper for precise pick-and-place of components with the cross-roller guide holding tight positional accuracy over the 20 mm stroke.
Small-Parts Transfer
Transfers small parts between stations with the symmetrical dual-rod table maintaining straight travel and minimal deflection.
Assembly Stage Stop
Serves as a guided stopper or positioning stage in an assembly line where the AS rubber stopper cushions the extension end of travel.
FAQ
What does the AS adjuster code mean on this model?
The AS code indicates an adjustable rubber stopper on the extension (forward) side of the cylinder. It lets you fine-tune the end-of-stroke cushioning on the extension end while the retraction end has the basic bumper.
What is the maximum operating pressure for this bore 12 cylinder?
The maximum working pressure is 0.7 MPa (100 psi). The operating pressure range for bore 12 and larger is 0.15-0.7 MPa (22-100 psi). Never exceed 0.7 MPa; proof pressure is 1.2 MPa.
