Airtac HLSL Precision Slide Table Cylinder HLSL12X30S
The AirTAC Airtac HLSL Precision Slide Table Cylinder HLSL12X30S is a genuine HLS slide-table cylinder, 12 mm bore: a double-acting dual-rod air cylinder integrated with a cross-roller guide so the table travels straight with high rigidity and low deflection. It delivers about 85 N of push at 0.5 MPa. This is the symmetrical version. A floating joint spares the rod from side torque; the magnet is fitted as standard.
- TypeSlide-table, double acting
- Guidecross-roller guide
- Bore12 mm
- Push thrust @0.5 MPa85 N
- Operating pressure0.15 - 0.7 MPa (22 - 100 psi)
- Port sizeM5x0.8
- CushionBumper (+ shock-absorber option)
- Magnet / sensorStandard; CMSH/DMSH/EMSH
- ThreadPT
About the Airtac HLSL Precision Slide Table Cylinder HLSL12X30S
The AirTAC HLSL12X30S is a symmetrical cross-roller guided slide-table cylinder with a 12 mm bore and 30 mm stroke. It integrates a double-acting dual-rod air cylinder with a high-rigidity cross-roller linear guide, so the moving table travels in a straight line with very low deflection. The dual rod provides moderate thrust for this bore size, and the floating joint prevents side torque from loading the rod.
This is a genuine AirTAC part with a standard magnet fitted for position sensing using CMSH, DMSH or EMSH switches in the body slots. We confirm exact thrust, dimensions, allowable load, moment and kinetic-energy figures from the AirTAC datasheet or on-page specification table on request.
Airtac HLSL Precision Slide Table Cylinder HLSL12X30S Technical Specifications
| Model | Airtac HLSL Precision Slide Table Cylinder HLSL12X30S |
|---|---|
| Type | Slide-table cylinder, double acting, dual rod |
| Series / guide | HLSL (cross-roller guide) |
| Bore | 12 mm |
| Push thrust @0.5 MPa | 85 N |
| Port size | M5x0.8 (PT thread) |
| Fluid | Air, filtered to 40 um |
|---|---|
| Operating pressure | 0.15 - 0.7 MPa (22 - 100 psi) |
| Proof pressure | 1.2 MPa (175 psi) |
| Temperature | -20 to 70 C |
| Speed range | 50 - 500 mm/s (meter-out) |
| Cushion | Bumper; shock-absorber / adjustable-stopper options |
| Magnet / sensor | Standard; CMSH, DMSH, EMSH |
Specifications follow the official AirTAC HL slide-table data. Max working pressure is 0.7 MPa. The table rides on an integrated linear guide — do not apply strong impact or large moment. Allowable load and moment are published as tables and curves, and overall dimensions vary per stroke — ask us and we confirm from the datasheet.
How to choose
A 12 mm bore gives moderate thrust suited to small-parts handling; select a larger bore when more push force is needed. The HLSL cross-roller guide offers the highest precision and rigidity in the HL family, and the symmetrical layout aids mounting from either side. This is the basic stopper version with bumper cushioning; for heavier impact energy consider the A or B adjuster options. Stroke must be within the bore 12 range in the datasheet.
Applications
Small-Parts Transfer
Cross-roller straightness moves small components precisely between two stations on a 30 mm stroke transfer slide.
Assembly Stage Positioning
The symmetrical body mounts in tight assembly fixtures where access from either side is needed for precise guided placement.
Stopper Gate
Moderate thrust and low deflection make a reliable stop gate that halts parts on a conveyor with repeatable positioning.
FAQ
Is the magnet optional on the HLSL12X30S?
No. The S in the model code indicates a magnet is fitted as standard on the entire HLS/HLSL line. It is not an option to decline. CMSH, DMSH and EMSH sensors slot into the body for position detection.
How fast can this slide table cycle?
Operating speed is 50-500 mm/s using meter-out speed control. Keep the maximum working pressure at 0.7 MPa; for bore 12 the operating range is 0.15-0.7 MPa (22-100 psi).
