Airtac HLSL Precision Slide Table Cylinder HLSL12X30SA
The AirTAC Airtac HLSL Precision Slide Table Cylinder HLSL12X30SA is a genuine HLS slide-table cylinder, 12 mm bore: a double-acting dual-rod air cylinder integrated with a cross-roller guide so the table travels straight with high rigidity and low deflection. It delivers about 85 N of push at 0.5 MPa. This is the symmetrical version. A floating joint spares the rod from side torque; the magnet is fitted as standard.
- TypeSlide-table, double acting
- Guidecross-roller guide
- Bore12 mm
- Push thrust @0.5 MPa85 N
- Operating pressure0.15 - 0.7 MPa (22 - 100 psi)
- Port sizeM5x0.8
- CushionBumper (+ shock-absorber option)
- Magnet / sensorStandard; CMSH/DMSH/EMSH
- ThreadPT
About the Airtac HLSL Precision Slide Table Cylinder HLSL12X30SA
The AirTAC HLSL12X30SA is a symmetrical cross-roller guided slide-table cylinder with a 12 mm bore and 30 mm stroke. The dual-rod, double-acting air cylinder is integrated with a high-precision cross-roller linear guide so the table travels straight with minimal deflection. The dual rod provides moderate thrust, the floating joint shields the rod from side torque, and the A adjuster adds adjustable rubber stoppers at both ends for tuned end-of-stroke positioning.
This is a genuine AirTAC part with a standard magnet for position sensing via CMSH, DMSH or EMSH switches in the body slots. We confirm thrust, dimensions, allowable load, moment and kinetic-energy values from the AirTAC datasheet or on-page specification table on request.
Airtac HLSL Precision Slide Table Cylinder HLSL12X30SA Technical Specifications
| Model | Airtac HLSL Precision Slide Table Cylinder HLSL12X30SA |
|---|---|
| Type | Slide-table cylinder, double acting, dual rod |
| Series / guide | HLSL (cross-roller guide) |
| Bore | 12 mm |
| Push thrust @0.5 MPa | 85 N |
| Port size | M5x0.8 (PT thread) |
| Fluid | Air, filtered to 40 um |
|---|---|
| Operating pressure | 0.15 - 0.7 MPa (22 - 100 psi) |
| Proof pressure | 1.2 MPa (175 psi) |
| Temperature | -20 to 70 C |
| Speed range | 50 - 500 mm/s (meter-out) |
| Cushion | Bumper; shock-absorber / adjustable-stopper options |
| Magnet / sensor | Standard; CMSH, DMSH, EMSH |
Specifications follow the official AirTAC HL slide-table data. Max working pressure is 0.7 MPa. The table rides on an integrated linear guide — do not apply strong impact or large moment. Allowable load and moment are published as tables and curves, and overall dimensions vary per stroke — ask us and we confirm from the datasheet.
How to choose
A 12 mm bore gives moderate thrust for guided small-parts handling; step up to a larger bore when more push is required. The cross-roller guide provides the highest precision and rigidity among the HL sub-families, and the symmetrical body aids mounting from either side. The A-code rubber stoppers let you fine-tune the stop position at both ends of the 30 mm stroke. Stroke must remain within the bore 12 range in the datasheet.
Applications
Precision Pick-and-Place
Adjustable rubber stoppers allow fine-tuned end positions for repeatable part placement on a cross-roller guided pick-and-place head.
Transfer Diverter
Symmetrical body and 30 mm stroke divert small parts between two conveyor lanes with low deflection and consistent travel.
Adjustable Stopper Slide
Rubber stoppers at both ends let operators dial in the stop position precisely for a fixture or clamping stage.
FAQ
What does the A in HLSL12X30SA indicate?
A means adjustable rubber stoppers are fitted at both ends of the stroke, letting you fine-tune the end-of-travel stop position. This is one of several adjuster options available on the HLS/HLSL family.
Can I get load and moment data for this model?
Yes. Allowable load, moment and table deflection are published as tables and curves in the AirTAC datasheet. We confirm the specific values for your bore 12, stroke 30 application on request rather than stating a generic figure.
