Airtac HLSL Precision Slide Table Cylinder HLSL12X30SB
The AirTAC Airtac HLSL Precision Slide Table Cylinder HLSL12X30SB is a genuine HLS slide-table cylinder, 12 mm bore: a double-acting dual-rod air cylinder integrated with a cross-roller guide so the table travels straight with high rigidity and low deflection. It delivers about 85 N of push at 0.5 MPa. This is the symmetrical version. A floating joint spares the rod from side torque; the magnet is fitted as standard.
- TypeSlide-table, double acting
- Guidecross-roller guide
- Bore12 mm
- Push thrust @0.5 MPa85 N
- Operating pressure0.15 - 0.7 MPa (22 - 100 psi)
- Port sizeM5x0.8
- CushionBumper (+ shock-absorber option)
- Magnet / sensorStandard; CMSH/DMSH/EMSH
- ThreadPT
- No minimum order. A single piece can be ordered.
- Ready in 3–5 business days. That is the time we take to process the order and hand it to the carrier. Transit time after that depends on the destination.
About the Airtac HLSL Precision Slide Table Cylinder HLSL12X30SB
The AirTAC HLSL12X30SB is a symmetrical cross-roller slide-table cylinder that integrates a double-acting air cylinder with a precision linear guide. The bore 12 body with a 30 mm stroke uses a cross-roller guide for high rigidity and low deflection, while the dual-rod design doubles thrust and a floating joint spares the rods from side torque. The B adjuster equips both ends with shock absorbers for smooth deceleration at higher cycling speeds.
This is a genuine AirTAC part with a standard sintered NdFeB magnet for position sensing using CMSH, DMSH or EMSH switches. We confirm thrust, dimensions, and load-moment values from the AirTAC datasheet or on-page spec table on request.
Airtac HLSL Precision Slide Table Cylinder HLSL12X30SB Technical Specifications
| Model | Airtac HLSL Precision Slide Table Cylinder HLSL12X30SB |
|---|---|
| Type | Slide-table cylinder, double acting, dual rod |
| Series / guide | HLSL (cross-roller guide) |
| Bore | 12 mm |
| Push thrust @0.5 MPa | 85 N |
| Port size | M5x0.8 (PT thread) |
| Fluid | Air, filtered to 40 um |
|---|---|
| Operating pressure | 0.15 - 0.7 MPa (22 - 100 psi) |
| Proof pressure | 1.2 MPa (175 psi) |
| Temperature | -20 to 70 C |
| Speed range | 50 - 500 mm/s (meter-out) |
| Cushion | Bumper; shock-absorber / adjustable-stopper options |
| Magnet / sensor | Standard; CMSH, DMSH, EMSH |
Specifications follow the official AirTAC HL slide-table data. Max working pressure is 0.7 MPa. The table rides on an integrated linear guide — do not apply strong impact or large moment. Allowable load and moment are published as tables and curves, and overall dimensions vary per stroke — ask us and we confirm from the datasheet.
How to choose
Bore 12 delivers moderate thrust for medium-duty guided tasks; choose a bigger bore when you need more push. The cross-roller guide in the HLS/HLSL sub-family offers the highest precision and rigidity among the HL line, making it the pick where deflection must be minimized. The symmetrical HLSL body suits layouts that need balanced dimensions on both sides. The B code means shock absorbers are fitted on both ends, which is recommended when cycling speeds are higher and you need controlled deceleration; thread is PT as standard (specify G or T for other thread types). We route allowable load and moment sizing to the published tables and deflection curves on request.
Applications
High-Cycle Stopper
Shock absorbers on both ends cushion the cross-roller slide at high cycle rates, making it a precise stopper for fast-indexing lines.
Parts Divert Slide
Dual-rod thrust and cross-roller rigidity push a divert gate across a conveyor with smooth, shock-absorbed stops at both ends.
Probe Positioning Stage
Low deflection and symmetrical body keep a test probe aligned as it extends and retracts 30 mm under a measurement head.
FAQ
What does the B adjuster code mean on this model?
The B code equips both the extension and retraction ends with shock absorbers, providing controlled deceleration at both stroke ends, which is recommended for higher cycling speeds or heavier moving loads.
What is the maximum operating pressure for bore 12?
Maximum working pressure is 0.7 MPa (100 psi). For bore 12 the operating range is 0.15-0.7 MPa (22-100 psi). Use meter-out speed control to keep travel between 50-500 mm/s.
