Airtac HLSL Precision Slide Table Cylinder HLSL12X30SBF
2、Pre-equipped positioning pin holes on guide rail for accurate mounting
3、Floating joint design prevents piston rod from bearing additional torsional loads
4、Dual piston rod configuration achieves double output force
5、Integrated positioning pin holes on main body for secure installation
6、Mounting screw holes provided on base surface and end faces
Category: Precision Slide Cylinder , Brand: AirTAC , Series: HLSL
AirTAC HLSL12X30SBF Precision Slide Table Cylinder Specifications
- Model: HLSL12X30SBF
- Structure: Twin-axis guided slide table with integrated linear guide rails
- Bore size: 12mm
- Stroke: 30mm (±0.5mm tolerance)
- Operating pressure: 0.1–0.9 MPa
- Cushioning: Adjustable pneumatic cushion (both ends)
- Seal material: NBR + Special polyurethane compound
- Temperature range: -10℃ to 80℃
- Mounting: Dual side mounting holes (M4×0.7) + base mounting slots
- Port size: M5×0.8 (Rc1/8 adaptor optional)
- Repeat positioning accuracy: ≤±0.01mm
- Max sliding speed: 500mm/s
- Weight: 0.56kg (excluding accessories)
- Dimensions: 130mm(L) × 34mm(W) × 34mm(H)
- Rod end thread: M6×1.0 internal thread
- Lubrication: Pre-lubricated (maintenance-free for 2,000km travel)
Ultra-precision guided cylinder featuring hardened steel linear guides with ball bearing recirculation system. Engineered for micron-level repeatability in cleanroom-compatible anodized aluminum construction. Integrated scraper seals prevent particulate ingress, with dual shock absorption for high-cycle applications. Requires ISO 8573-1:2010 Class 3 compressed air.
- Semiconductor wafer handling robots
- Micro-dispensing systems in PCB assembly
- Optical lens alignment mechanisms
- High-speed pick-and-place with vision inspection
- Medical device precision actuation
Installation note:
Use torque-controlled tightening (0.7-1.2N·m for M4 screws) to prevent guide rail deformation.
Maintain 0.02-0.05mm clearance between stopper and slide block during alignment.
| Property | Property Value |
|---|---|
| sku | HLSL12X30SBF |
| External Stop Block Type | Retract End Hydraulic Cushion |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20-70°C Speed Range: 50-500 mm/s |
| Port Size | M5×0.8 |
| Magnet | S-Magnetic |
| Bore Diameter | 12mm |
| Stroke | 30mm |
