Airtac HLSL Precision Slide Table Cylinder HLSL12X30SBS
The AirTAC Airtac HLSL Precision Slide Table Cylinder HLSL12X30SBS is a genuine HLS slide-table cylinder, 12 mm bore: a double-acting dual-rod air cylinder integrated with a cross-roller guide so the table travels straight with high rigidity and low deflection. It delivers about 85 N of push at 0.5 MPa. This is the symmetrical version. A floating joint spares the rod from side torque; the magnet is fitted as standard.
- TypeSlide-table, double acting
- Guidecross-roller guide
- Bore12 mm
- Push thrust @0.5 MPa85 N
- Operating pressure0.15 - 0.7 MPa (22 - 100 psi)
- Port sizeM5x0.8
- CushionBumper (+ shock-absorber option)
- Magnet / sensorStandard; CMSH/DMSH/EMSH
- ThreadPT
- No minimum order. A single piece can be ordered.
- Ready in 3–5 business days. That is the time we take to process the order and hand it to the carrier. Transit time after that depends on the destination.
About the Airtac HLSL Precision Slide Table Cylinder HLSL12X30SBS
The AirTAC HLSL12X30SBS is a symmetrical cross-roller slide-table cylinder with a 12 mm bore and 30 mm stroke. The cross-roller linear guide integrates with the air cylinder so the table moves straight with high rigidity and minimal deflection. Dual rods double the thrust and a floating joint protects them from side torque. A shock absorber at the extension end cushions the forward stop.
This is a genuine AirTAC part. A sintered NdFeB magnet is standard for position sensing with CMSH, DMSH or EMSH switches fitted in the body slots. We confirm thrust, dimensions and load-moment ratings from the AirTAC datasheet or on-page spec table on request.
Airtac HLSL Precision Slide Table Cylinder HLSL12X30SBS Technical Specifications
| Model | Airtac HLSL Precision Slide Table Cylinder HLSL12X30SBS |
|---|---|
| Type | Slide-table cylinder, double acting, dual rod |
| Series / guide | HLSL (cross-roller guide) |
| Bore | 12 mm |
| Push thrust @0.5 MPa | 85 N |
| Port size | M5x0.8 (PT thread) |
| Fluid | Air, filtered to 40 um |
|---|---|
| Operating pressure | 0.15 - 0.7 MPa (22 - 100 psi) |
| Proof pressure | 1.2 MPa (175 psi) |
| Temperature | -20 to 70 C |
| Speed range | 50 - 500 mm/s (meter-out) |
| Cushion | Bumper; shock-absorber / adjustable-stopper options |
| Magnet / sensor | Standard; CMSH, DMSH, EMSH |
Specifications follow the official AirTAC HL slide-table data. Max working pressure is 0.7 MPa. The table rides on an integrated linear guide — do not apply strong impact or large moment. Allowable load and moment are published as tables and curves, and overall dimensions vary per stroke — ask us and we confirm from the datasheet.
How to choose
A 12 mm bore provides moderate thrust in this cross-roller guided slide; choose a larger bore when more push is needed. The HLS cross-roller guide delivers the highest precision and rigidity in the HL family, and the symmetrical HLSL layout balances the load. Adjuster code BS places a shock absorber on the extension side for smooth forward stopping. The 30 mm stroke fits within the bore 12 range. Ports use PT threads. Contact us for allowable load and moment values, which are published as tables and deflection curves.
Applications
Component Placement
Cross-roller precision and an extension-side shock absorber suit this model for placing small parts onto a fixture with controlled forward stop.
Lane Transfer Pusher
The dual-rod slide moves lightweight items between conveyor lanes at 30 mm stroke with consistent repeatable positioning.
Assembly Station Slide
Symmetrical mounting and shock-absorber cushioning make this guided table a good fit for advancing a workpiece into an assembly or test position.
FAQ
What does the BS adjuster code mean?
B specifies a shock absorber and S places it on the extension side. It cushions the table as it reaches the forward end of the 30 mm stroke, reducing impact forces.
Can I use this cylinder above 0.7 MPa?
No. The maximum working pressure is 0.7 MPa. For a 12 mm bore the operating range is 0.15-0.7 MPa (22-100 psi). Proof pressure is 1.2 MPa for validation only.
