Airtac HLSL Precision Slide Table Cylinder HLSL12X40SA
The AirTAC Airtac HLSL Precision Slide Table Cylinder HLSL12X40SA is a genuine HLS slide-table cylinder, 12 mm bore: a double-acting dual-rod air cylinder integrated with a cross-roller guide so the table travels straight with high rigidity and low deflection. It delivers about 85 N of push at 0.5 MPa. This is the symmetrical version. A floating joint spares the rod from side torque; the magnet is fitted as standard.
- TypeSlide-table, double acting
- Guidecross-roller guide
- Bore12 mm
- Push thrust @0.5 MPa85 N
- Operating pressure0.15 - 0.7 MPa (22 - 100 psi)
- Port sizeM5x0.8
- CushionBumper (+ shock-absorber option)
- Magnet / sensorStandard; CMSH/DMSH/EMSH
- ThreadPT
- No minimum order. A single piece can be ordered.
- Ready in 3–5 business days. That is the time we take to process the order and hand it to the carrier. Transit time after that depends on the destination.
About the Airtac HLSL Precision Slide Table Cylinder HLSL12X40SA
The AirTAC HLSL12X40SA is a symmetrical cross-roller slide-table cylinder that integrates a dual-rod air cylinder with a precision linear guide, so the work-table travels straight with low deflection. The bore 12 body delivers moderate thrust in a compact footprint, and the floating joint spares both rods from side torque so the guide stays accurate over a long service life. Stroke is 40 mm.
This is a genuine AirTAC part with a standard sintered magnet for position sensing; compatible sensor switches are CMSH, DMSH, and EMSH series, which seat in the body slots. We confirm thrust values, dimensions, and load-moment ratings from the datasheet or on-page spec table on request.
Airtac HLSL Precision Slide Table Cylinder HLSL12X40SA Technical Specifications
| Model | Airtac HLSL Precision Slide Table Cylinder HLSL12X40SA |
|---|---|
| Type | Slide-table cylinder, double acting, dual rod |
| Series / guide | HLSL (cross-roller guide) |
| Bore | 12 mm |
| Push thrust @0.5 MPa | 85 N |
| Port size | M5x0.8 (PT thread) |
| Fluid | Air, filtered to 40 um |
|---|---|
| Operating pressure | 0.15 - 0.7 MPa (22 - 100 psi) |
| Proof pressure | 1.2 MPa (175 psi) |
| Temperature | -20 to 70 C |
| Speed range | 50 - 500 mm/s (meter-out) |
| Cushion | Bumper; shock-absorber / adjustable-stopper options |
| Magnet / sensor | Standard; CMSH, DMSH, EMSH |
Specifications follow the official AirTAC HL slide-table data. Max working pressure is 0.7 MPa. The table rides on an integrated linear guide — do not apply strong impact or large moment. Allowable load and moment are published as tables and curves, and overall dimensions vary per stroke — ask us and we confirm from the datasheet.
How to choose
Choose bore 12 when you need moderate thrust in a compact cross-roller slide table; a larger bore gives more push and a smaller bore saves space. The cross-roller guide suits applications demanding high rigidity and low deflection. Stroke 40 mm falls within the bore 12 stroke table. The A adjuster adds adjustable rubber stoppers at both ends for fine end-position control. Thread is PT (tapered). Contact us to confirm allowable load, moment, and deflection curves from the published datasheet tables.
Applications
Pick-and-Place Head
Mounts a small gripper for precise part transfer between fixture stations with rubber-stopper control at both ends.
Small-Parts Transfer
Moves light components across a conveyor lane with straight, repeatable travel on the cross-roller guide.
Assembly Stage Stopper
Positions a workpiece at an assembly station, relying on the dual-rod design for stable, torque-free clamping.
FAQ
What does the SA adjuster mean on the HLSL12X40SA?
The A in SA stands for adjustable rubber stoppers at both ends, giving you fine end-position control on both the extension and retraction strokes without adding a shock absorber.
What is the maximum operating pressure for the HLSL12 bore 12?
Maximum working pressure is 0.7 MPa (100 psi). The operating pressure range for bore 12 is 0.15-0.7 MPa (22-100 psi). Meter-out speed control keeps travel within 50-500 mm/s.
