Airtac JCK High Strength Welding Clamping Cylinder JCK40X105
1. Patented crank-slider mechanism (constructed with high-strength, wear-resistant materials): a) Ensures structural stability and generates exceptional clamping force with minimal air pressure through high mechanical efficiency. b) Integrated self-locking mechanism maintains clamping force even during air supply interruption.
2. DIN-compliant four-side mounting configuration for flexible installation options.
3. Monolithic design integrating clamping mechanism with pneumatic cylinder for enhanced structural integrity.
4. Specially engineered sensor bracket with anti-spatter design and ±15° adjustable angles, featuring anti-interference shielding for stable signal transmission.
5. Space-efficient oval-shaped cylinder housing optimizes equipment layout in confined spaces.
6. Modular clamp arms (AM1/AM2/AM3/AM4) with R/C/L variants (radial/vertical/lateral orientations) adapt to diverse operational demands.
7. Tool-free opening angle adjustment via replacement of adjustment screws (15°-180° range).
Category: Welding Clamping Cylinders | Brand: AIRTAC | Series: JCK
AirTAC JCK Series Heavy-Duty Welding Clamping Cylinder JCK40X105 Specifications
- Model: JCK40X105
- Bore size: 40mm
- Stroke: 105mm
- Operating pressure: 0.1–0.9 MPa
- Max thrust: 1,256N @0.7MPa
- Cushioning: Adjustable pneumatic cushion
- Mounting type: SW (Standard square base)
- Rod end thread: M20×1.5
- Material: Aluminum alloy body, chrome-plated piston rod
- Seal type: NBR/PU seals
- Ambient temperature: -20℃ to 80℃
- Weight: 3.7kg (excluding accessories)
- Dimensions: 275mm(L) × 60mm(W) × 60mm(H) (Fully extended)
- Port size: G1/8
- Protection class: IP54 (Standard)
- Lubrication: Pre-lubricated (Requires periodic relubrication)
Robust welding-grade cylinder with reinforced structure for high-moment applications. Features double piston seals and anti-spatter coating (optional) for enhanced durability in harsh manufacturing environments. Requires filtered air with 50μm filtration and oil mist lubrication for optimal performance.
- Automotive welding fixture clamping
- Heavy plate positioning in shipbuilding
- Press brake tooling fixation
- Forging machine workholding
- Foundry equipment mold locking
Installation note:
Mount using Class 12.9 bolts with spring washers. Maintain 0.5-1mm clearance between
clamping face and workpiece. Perform weekly lubrication checks in high-cycle applications
(>5,000 cycles/day). Avoid lateral loads exceeding 150N.
| Property | Property Value |
|---|---|
| sku | JCK40X105 |
| Clamping Arm Position Code | Clamping Arm Horizontal |
| Clamping Arm Model Code | Without Clamping Arm |
| Opening Angle | 105mm |
| Port Size | PT1/8 |
| Bore Diameter | <40mm> |
