Airtac JCK High Strength Welding Clamping Cylinder JCK40X105AM1C
1. Patented crank-slider mechanism (constructed with high-strength, wear-resistant materials): a) Ensures structural stability and generates exceptional clamping force with minimal air pressure through high mechanical efficiency. b) Integrated self-locking mechanism maintains clamping force even during air supply interruption.
2. DIN-compliant four-side mounting configuration for flexible installation options.
3. Monolithic design integrating clamping mechanism with pneumatic cylinder for enhanced structural integrity.
4. Specially engineered sensor bracket with anti-spatter design and ±15° adjustable angles, featuring anti-interference shielding for stable signal transmission.
5. Space-efficient oval-shaped cylinder housing optimizes equipment layout in confined spaces.
6. Modular clamp arms (AM1/AM2/AM3/AM4) with R/C/L variants (radial/vertical/lateral orientations) adapt to diverse operational demands.
7. Tool-free opening angle adjustment via replacement of adjustment screws (15°-180° range).
Category: Welding Clamping Cylinders | Brand: AIRTAC | Series: JCK
AirTAC JCK40X105AM1C Heavy-Duty Welding Clamp Cylinder Specifications
- Model: JCK40X105AM1C
- Bore size: 40mm
- Stroke: 105mm
- Operating pressure: 0.05–1.0 MPa
- Max thrust: 1256N (at 1.0 MPa)
- Mounting type: AM series fixed mounting
- Piston material: High-strength aluminum alloy with hard anodizing
- Rod material: Chrome-plated steel (Cr-Mo)
- Seal type: Heat-resistant NBR seals (up to 120℃ intermittent)
- Buffer type: Adjustable rubber cushion
- Ambient temperature: -20℃ to 80℃
- Weight: 2.65kg ±2%
- Dimensions:
- Length (retracted): 219mm
- Width (body): 58mm
- Height (mounting base): 82mm
- Rod end thread: M20×1.5
- Protection rating: IP54 (standard), IP67 optional
- Lubrication: Pre-lubricated (DOP anti-wear oil)
Industrial-grade welding clamp cylinder with reinforced structure and spatter-resistant design. Features a hardened piston rod with double-layer chrome plating (20-25μm) for arc welding environments. The enhanced guide mechanism reduces lateral deflection by 30% compared to standard models. Requires 5μm filtered air with oil mist lubrication recommended for continuous operation.
- Robotic welding fixture systems
- Automotive frame jig positioning
- Heavy plate pressing in shipbuilding
- High-temperature mold clamping (die casting applications)
- Forging machine workpiece retention
Installation warning:
When used in welding environments, install thermal barrier shield (P/N: JCK-TS40)
within 500mm of cylinder body. Maintain 1.5mm minimum clearance between rod
and spatter sources. Perform weekly rod surface cleaning using silicone-coated wipes.
| Property | Property Value |
|---|---|
| sku | JCK40X105AM1C |
| Clamping Arm Position Code | Clamping Arm Horizontal |
| Clamping Arm Model Code | Offset 15mm |
| Opening Angle | 105mm |
| Port Size | PT1/8 |
| Bore Diameter | <40mm> |
