Airtac JCK High Strength Welding Clamping Cylinder JCK40X105AM1CK
$283.78
Regular price
$291.28
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
JCK40X105AM1CK
Product type:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
JCK Heavy-duty Welding Clamp Cylinder
1. Patented crank-slider mechanism (constructed with high-strength, wear-resistant materials): a) Ensures structural stability and generates exceptional clamping force with minimal air pressure through high mechanical efficiency. b) Integrated self-locking mechanism maintains clamping force even during air supply interruption.
2. DIN-compliant four-side mounting configuration for flexible installation options.
3. Monolithic design integrating clamping mechanism with pneumatic cylinder for enhanced structural integrity.
4. Specially engineered sensor bracket with anti-spatter design and ±15° adjustable angles, featuring anti-interference shielding for stable signal transmission.
5. Space-efficient oval-shaped cylinder housing optimizes equipment layout in confined spaces.
6. Modular clamp arms (AM1/AM2/AM3/AM4) with R/C/L variants (radial/vertical/lateral orientations) adapt to diverse operational demands.
7. Tool-free opening angle adjustment via replacement of adjustment screws (15°-180° range).
Category: Welding Clamping Cylinders | Brand: AIRTAC | Series: JCK
Installation note:
Apply anti-seize compound on piston rod threads before first use.
Requires 5-20μm filtration with ISO 8573-1:2010 Class 3.4.2 air quality.
Torque limit: 12N·m for mounting bolts.
1. Patented crank-slider mechanism (constructed with high-strength, wear-resistant materials): a) Ensures structural stability and generates exceptional clamping force with minimal air pressure through high mechanical efficiency. b) Integrated self-locking mechanism maintains clamping force even during air supply interruption.
2. DIN-compliant four-side mounting configuration for flexible installation options.
3. Monolithic design integrating clamping mechanism with pneumatic cylinder for enhanced structural integrity.
4. Specially engineered sensor bracket with anti-spatter design and ±15° adjustable angles, featuring anti-interference shielding for stable signal transmission.
5. Space-efficient oval-shaped cylinder housing optimizes equipment layout in confined spaces.
6. Modular clamp arms (AM1/AM2/AM3/AM4) with R/C/L variants (radial/vertical/lateral orientations) adapt to diverse operational demands.
7. Tool-free opening angle adjustment via replacement of adjustment screws (15°-180° range).
Category: Welding Clamping Cylinders | Brand: AIRTAC | Series: JCK
AirTAC JCK40X105AM1CK Heavy-Duty Welding Clamping Cylinder Specifications
- Model: JCK40X105AM1CK
- Type: Double-acting welded clamping cylinder
- Bore size: 40mm
- Stroke: 105mm
- Operating pressure: 0.1–1.0 MPa
- Port size: G1/8 (Rc1/8 optional)
- Cushioning: Adjustable pneumatic cushion
- Mounting style: Rectangular flange with through holes
- Material: Hard anodized aluminum body, CRMo steel piston rod
- Temperature range: -10℃ to 80℃
- Protection rating: IP67 (wipers included)
- Magnetic switch: Pre-installed M9 connector (2-wire)
- Weight: 2.45kg (excluding accessories)
- Dimensions: 200mm(L) × 80mm(W) × 80mm(H) (full extension)
Industrial-grade clamping cylinder specifically engineered for high vibration environments with integrated anti-loosening structure. Features double-sealed piston (NBR + polyurethane) and phosphate-coated rod surface for welding spatter resistance. Includes 4xM6 mounting holes with vibration-damping washers.
Typical Applications:
- Robotic welding fixture systems
- Automotive chassis component clamping
- Forging press tool positioning
- Heavy part alignment in CNC machining centers
- High-temperature mold locking mechanisms
Installation note:
Apply anti-seize compound on piston rod threads before first use.
Requires 5-20μm filtration with ISO 8573-1:2010 Class 3.4.2 air quality.
Torque limit: 12N·m for mounting bolts.
Maintenance Protocol:
- Relubricate every 500,000 cycles (Use ISO VG32 hydraulic oil)
- Inspect rod wipers every 2,000 operating hours
- Max side load capacity: 350N at full extension
| Property | Property Value |
|---|---|
| sku | JCK40X105AM1CK |
| Clamping Arm Position Code | Clamping Arm Horizontal |
| Clamping Arm Model Code | Offset 15mm |
| Opening Angle | 105mm |
| Port Size | PT1/8 |
| Bore Diameter | <40mm> |
