Airtac JCK High Strength Welding Clamping Cylinder JCK40X105AM1CKA
$351.25
Regular price
$358.75
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
JCK40X105AM1CKA
Product type:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
JCK Heavy-duty Welding Clamp Cylinder
1. Patented crank-slider mechanism (constructed with high-strength, wear-resistant materials): a) Ensures structural stability and generates exceptional clamping force with minimal air pressure through high mechanical efficiency. b) Integrated self-locking mechanism maintains clamping force even during air supply interruption.
2. DIN-compliant four-side mounting configuration for flexible installation options.
3. Monolithic design integrating clamping mechanism with pneumatic cylinder for enhanced structural integrity.
4. Specially engineered sensor bracket with anti-spatter design and ±15° adjustable angles, featuring anti-interference shielding for stable signal transmission.
5. Space-efficient oval-shaped cylinder housing optimizes equipment layout in confined spaces.
6. Modular clamp arms (AM1/AM2/AM3/AM4) with R/C/L variants (radial/vertical/lateral orientations) adapt to diverse operational demands.
7. Tool-free opening angle adjustment via replacement of adjustment screws (15°-180° range).
Category: Welding Clamping Cylinders | Brand: AIRTAC | Series: JCK
Installation requirements:
Ensure guide rod alignment within 0.2mm/m tolerance. Use locknuts with 25-30N·m torque.
Lubricate with ISO VG32 hydraulic oil before initial operation. Avoid side impact forces exceeding 300N.
1. Patented crank-slider mechanism (constructed with high-strength, wear-resistant materials): a) Ensures structural stability and generates exceptional clamping force with minimal air pressure through high mechanical efficiency. b) Integrated self-locking mechanism maintains clamping force even during air supply interruption.
2. DIN-compliant four-side mounting configuration for flexible installation options.
3. Monolithic design integrating clamping mechanism with pneumatic cylinder for enhanced structural integrity.
4. Specially engineered sensor bracket with anti-spatter design and ±15° adjustable angles, featuring anti-interference shielding for stable signal transmission.
5. Space-efficient oval-shaped cylinder housing optimizes equipment layout in confined spaces.
6. Modular clamp arms (AM1/AM2/AM3/AM4) with R/C/L variants (radial/vertical/lateral orientations) adapt to diverse operational demands.
7. Tool-free opening angle adjustment via replacement of adjustment screws (15°-180° range).
Category: Welding Clamping Cylinders | Brand: AIRTAC | Series: JCK
AirTAC JCK40X105AM1CKA Heavy-Duty Welding Clamp Cylinder Specifications
- Model: JCK40X105AM1CKA
- Series: JCK Welding Clamp Cylinder
- Bore size: 40mm
- Stroke: 105mm
- Operating pressure: 0.1–1.0 MPa
- Temperature range: -10℃ to 80℃
- Port size: G1/4 (ISO standard)
- Piston rod material: Hard chrome-plated steel
- Tube material: High-strength aluminum alloy (anodized)
- Buffer type: Adjustable rubber cushion
- Mounting style: Fixed base with 4x M6 threaded holes
- Anti-rotation mechanism: Dual guide rods (12mm diameter)
- Seal material: NBR + PU composite
- Protection rating: IP54 (standard), IP67 optional
- Weight: 3.8 kg (without accessories)
- Dimensions:
- Length: 315mm (fully retracted)
- Width: 78mm (mounting base)
- Height: 62mm (body diameter)
Industrial-grade clamping cylinder featuring reinforced welding structure and anti-torsion design. The dual guide rod configuration ensures precise linear motion under heavy lateral loads. Enhanced preload mechanism delivers up to 1,256N clamping force at 0.5MPa. Rated for 5,000km service life with proper maintenance.
Typical Applications:
- Robotic welding fixture systems
- High-vibration stamping press tooling
- Automotive chassis component assembly
- Foundry mold clamping operations
- Heavy workpiece positioning jigs
Installation requirements:
Ensure guide rod alignment within 0.2mm/m tolerance. Use locknuts with 25-30N·m torque.
Lubricate with ISO VG32 hydraulic oil before initial operation. Avoid side impact forces exceeding 300N.
Maintenance:
Inspect seals every 500k cycles. Replace guide rod bushings when lateral play exceeds 0.5mm.
Clean air filter elements monthly in high particulate environments.
| Property | Property Value |
|---|---|
| sku | JCK40X105AM1CKA |
| Clamping Arm Position Code | Clamping Arm Horizontal |
| Clamping Arm Model Code | Offset 15mm |
| Opening Angle | 105mm |
| Port Size | PT1/8 |
| Bore Diameter | <40mm> |
