Airtac JCK High Strength Welding Clamping Cylinder JCK40X105AM1CKN
$283.78
Regular price
$291.28
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
JCK40X105AM1CKN
Product type:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
JCK Heavy-duty Welding Clamp Cylinder
1. Patented crank-slider mechanism (constructed with high-strength, wear-resistant materials): a) Ensures structural stability and generates exceptional clamping force with minimal air pressure through high mechanical efficiency. b) Integrated self-locking mechanism maintains clamping force even during air supply interruption.
2. DIN-compliant four-side mounting configuration for flexible installation options.
3. Monolithic design integrating clamping mechanism with pneumatic cylinder for enhanced structural integrity.
4. Specially engineered sensor bracket with anti-spatter design and ±15° adjustable angles, featuring anti-interference shielding for stable signal transmission.
5. Space-efficient oval-shaped cylinder housing optimizes equipment layout in confined spaces.
6. Modular clamp arms (AM1/AM2/AM3/AM4) with R/C/L variants (radial/vertical/lateral orientations) adapt to diverse operational demands.
7. Tool-free opening angle adjustment via replacement of adjustment screws (15°-180° range).
Category: Welding Clamping Cylinders | Brand: AIRTAC | Series: JCK
Installation guidelines:
Mount using Class 10.9 M8 bolts (recommended torque 28.5N·m).
Maintain 0.3-0.5mm clearance between clamp jaws and cylinder body during welding operations.
Lubricate every 5,000 cycles under continuous operation.
Critical notes:
Avoid lateral loading exceeding 200N. Maximum permissible side load: 15% of axial thrust.
Not recommended for vertical downward mounting without counterbalance.
1. Patented crank-slider mechanism (constructed with high-strength, wear-resistant materials): a) Ensures structural stability and generates exceptional clamping force with minimal air pressure through high mechanical efficiency. b) Integrated self-locking mechanism maintains clamping force even during air supply interruption.
2. DIN-compliant four-side mounting configuration for flexible installation options.
3. Monolithic design integrating clamping mechanism with pneumatic cylinder for enhanced structural integrity.
4. Specially engineered sensor bracket with anti-spatter design and ±15° adjustable angles, featuring anti-interference shielding for stable signal transmission.
5. Space-efficient oval-shaped cylinder housing optimizes equipment layout in confined spaces.
6. Modular clamp arms (AM1/AM2/AM3/AM4) with R/C/L variants (radial/vertical/lateral orientations) adapt to diverse operational demands.
7. Tool-free opening angle adjustment via replacement of adjustment screws (15°-180° range).
Category: Welding Clamping Cylinders | Brand: AIRTAC | Series: JCK
AirTAC JCK Heavy-Duty Welding Clamp Cylinder JCK40X105AM1CKN Specifications
- Model: JCK40X105AM1CKN
- Type: Double-acting welded clamp cylinder
- Bore size: 40mm
- Stroke: 105mm
- Operating pressure: 0.1–0.9 MPa
- Port size: G1/8 (ISO228 standard)
- Cushioning: Adjustable air cushion (both ends)
- Mounting style: Front flange (MF1) with reinforced base
- Temperature range: -20℃ to 80℃
- Seal material: Heat-resistant NBR (Nitrile rubber)
- Piston rod material: Chrome-plated carbon steel (S45C)
- Protection rating: IP54 (dust/water resistant)
- Built-in magnet: Yes (for position sensing)
- Weight: 1.7kg ±3%
- Dimensions: 196mm(L) × 56mm(W) × 56mm(H)
Industrial-grade welding clamp cylinder designed for high rigidity and impact resistance in harsh manufacturing environments. Features anti-spatter coating (0.5mm thickness) on the barrel surface and integrated shock-absorbing structure. Requires 5μm filtered compressed air with ISO VG32 hydraulic oil mist lubrication (0.1-0.3cc/m³).
Typical Applications:
- Robotic welding fixture positioning systems
- Press brake tooling clamping in metal fabrication
- Forging machine die retention mechanisms
- Heavy-duty conveyor jig locking
- Automotive frame assembly tooling
Installation guidelines:
Mount using Class 10.9 M8 bolts (recommended torque 28.5N·m).
Maintain 0.3-0.5mm clearance between clamp jaws and cylinder body during welding operations.
Lubricate every 5,000 cycles under continuous operation.
Critical notes:
Avoid lateral loading exceeding 200N. Maximum permissible side load: 15% of axial thrust.
Not recommended for vertical downward mounting without counterbalance.
| Property | Property Value |
|---|---|
| sku | JCK40X105AM1CKN |
| Clamping Arm Position Code | Clamping Arm Horizontal |
| Clamping Arm Model Code | Offset 15mm |
| Opening Angle | 105mm |
| Port Size | PT1/8 |
| Bore Diameter | <40mm> |
