Airtac JCK High Strength Welding Clamping Cylinder JCK40X105AM1L
1. Patented crank-slider mechanism (constructed with high-strength, wear-resistant materials): a) Ensures structural stability and generates exceptional clamping force with minimal air pressure through high mechanical efficiency. b) Integrated self-locking mechanism maintains clamping force even during air supply interruption.
2. DIN-compliant four-side mounting configuration for flexible installation options.
3. Monolithic design integrating clamping mechanism with pneumatic cylinder for enhanced structural integrity.
4. Specially engineered sensor bracket with anti-spatter design and ±15° adjustable angles, featuring anti-interference shielding for stable signal transmission.
5. Space-efficient oval-shaped cylinder housing optimizes equipment layout in confined spaces.
6. Modular clamp arms (AM1/AM2/AM3/AM4) with R/C/L variants (radial/vertical/lateral orientations) adapt to diverse operational demands.
7. Tool-free opening angle adjustment via replacement of adjustment screws (15°-180° range).
Category: Welding Clamping Cylinders | Brand: AIRTAC | Series: JCK
AirTAC JCK Series Heavy-Duty Welding Clamp Cylinder JCK40X105AM1L Specifications
- Model: JCK40X105AM1L
- Bore size: 40mm
- Stroke: 105mm
- Operation type: Double-acting
- Max operating pressure: 0.7 MPa (7 bar)
- Min operating pressure: 0.15 MPa (1.5 bar)
- Piston speed: 50-700 mm/s
- Cushioning type: Adjustable cushioning (both ends)
- Mounting style: Fixed side flange (MF1)
- Rod end type: External thread (M16x1.5)
- Ambient temperature: -20℃ to 80℃
- Material:
- Tube: Aluminum alloy hard oxidation
- Piston rod: Chrome-plated steel
- Seals: Heat-resistant NBR
- Weight: 3.2 kg ±5%
- Dimensions:
- Length (retracted): 205mm
- Width (flange): 58mm
- Height (mounting face): 76mm
- Rod extension: 105mm (max)
Industrial-grade welding clamp cylinder with reinforced structure for high moment resistance. Features dual-layer chrome plating on rod (20-25μm) and wear-resistant guide rings. Designed for 500,000+ cycle durability under continuous impact loads. Requires ISO 8573-1:2010 Class 3 lubricated air (ISO VG32 oil mist).
- Robotic welding fixture systems in automotive production lines
- High-temperature workpiece clamping in foundries
- Heavy part positioning in shipbuilding jigs
- Press machine mold securing mechanisms
- Forging equipment component retention
Installation warning:
Use anti-vibration locknuts (Grade 8.8 or higher) for mounting.
Maintain 0.5mm minimum clearance between rod end and workpiece during thermal expansion scenarios.
| Property | Property Value |
|---|---|
| sku | JCK40X105AM1L |
| Clamping Arm Position Code | Clamping Arm Horizontal |
| Clamping Arm Model Code | Offset 15mm |
| Opening Angle | 105mm |
| Port Size | PT1/8 |
| Bore Diameter | <40mm> |
