Airtac JCK High Strength Welding Clamping Cylinder JCK40X105AM1LKA
$351.25
Regular price
$358.75
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
JCK40X105AM1LKA
Product type:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
JCK Heavy-duty Welding Clamp Cylinder
1. Patented crank-slider mechanism (constructed with high-strength, wear-resistant materials): a) Ensures structural stability and generates exceptional clamping force with minimal air pressure through high mechanical efficiency. b) Integrated self-locking mechanism maintains clamping force even during air supply interruption.
2. DIN-compliant four-side mounting configuration for flexible installation options.
3. Monolithic design integrating clamping mechanism with pneumatic cylinder for enhanced structural integrity.
4. Specially engineered sensor bracket with anti-spatter design and ±15° adjustable angles, featuring anti-interference shielding for stable signal transmission.
5. Space-efficient oval-shaped cylinder housing optimizes equipment layout in confined spaces.
6. Modular clamp arms (AM1/AM2/AM3/AM4) with R/C/L variants (radial/vertical/lateral orientations) adapt to diverse operational demands.
7. Tool-free opening angle adjustment via replacement of adjustment screws (15°-180° range).
Category: Welding Clamping Cylinders | Brand: AIRTAC | Series: JCK
Installation notes:
1. Patented crank-slider mechanism (constructed with high-strength, wear-resistant materials): a) Ensures structural stability and generates exceptional clamping force with minimal air pressure through high mechanical efficiency. b) Integrated self-locking mechanism maintains clamping force even during air supply interruption.
2. DIN-compliant four-side mounting configuration for flexible installation options.
3. Monolithic design integrating clamping mechanism with pneumatic cylinder for enhanced structural integrity.
4. Specially engineered sensor bracket with anti-spatter design and ±15° adjustable angles, featuring anti-interference shielding for stable signal transmission.
5. Space-efficient oval-shaped cylinder housing optimizes equipment layout in confined spaces.
6. Modular clamp arms (AM1/AM2/AM3/AM4) with R/C/L variants (radial/vertical/lateral orientations) adapt to diverse operational demands.
7. Tool-free opening angle adjustment via replacement of adjustment screws (15°-180° range).
Category: Welding Clamping Cylinders | Brand: AIRTAC | Series: JCK
AirTAC JCK40X105AM1LKA Heavy-Duty Welding Clamping Cylinder Specifications
- Model: JCK40X105AM1LKA
- Type: Double-acting welded clamping cylinder
- Bore size: 40mm
- Stroke: 105mm
- Operating pressure: 0.15–0.8 MPa (21.7–116 PSI)
- Piston rod material: SUS304 stainless steel
- Cylinder tube: Hard anodized aluminum alloy
- Mounting style: Square front flange (AM1 type)
- Cushioning: Adjustable pneumatic cushion (both ends)
- Seal material: Heat-resistant NBR (-20℃ to 80℃)
- Anti-rotation mechanism: Integrated guide rod design
- Weight: 2.8 kg (6.17 lbs)
- Dimensions: 230mm(L) × 82mm(W) × 82mm(H)
- Port size: M5x0.8 (standard), G1/8 optional
- Max thrust: 502N @0.5MPa (extending)
- Protection rating: IP54 (standard dust/moisture resistance)
Professional-grade clamping cylinder engineered for high vibration environments with reinforced welding structure. Features triple-sealed guide mechanisms and tungsten-coated piston rods for extended service life in metal fabrication applications. Includes magnetic piston for position sensing compatibility.
Industrial Applications:
- Robotic welding fixture systems
- Automotive frame jig positioning
- Forging press auxiliary clamping
- High-temperature furnace door locking
- Heavy plate CNC machining centers
Installation notes:
- Use vibration-damping mounts in arc welding environments
- Maintain 0.3mm minimum clearance between guide rods and mating parts
- Apply molybdenum disulfide grease monthly in continuous operation
| Property | Property Value |
|---|---|
| sku | JCK40X105AM1LKA |
| Clamping Arm Position Code | Clamping Arm Horizontal |
| Clamping Arm Model Code | Offset 15mm |
| Opening Angle | 105mm |
| Port Size | PT1/8 |
| Bore Diameter | <40mm> |
