Airtac JCK High Strength Welding Clamping Cylinder JCK40X105AM1LKN
1. Patented crank-slider mechanism (constructed with high-strength, wear-resistant materials): a) Ensures structural stability and generates exceptional clamping force with minimal air pressure through high mechanical efficiency. b) Integrated self-locking mechanism maintains clamping force even during air supply interruption.
2. DIN-compliant four-side mounting configuration for flexible installation options.
3. Monolithic design integrating clamping mechanism with pneumatic cylinder for enhanced structural integrity.
4. Specially engineered sensor bracket with anti-spatter design and ±15° adjustable angles, featuring anti-interference shielding for stable signal transmission.
5. Space-efficient oval-shaped cylinder housing optimizes equipment layout in confined spaces.
6. Modular clamp arms (AM1/AM2/AM3/AM4) with R/C/L variants (radial/vertical/lateral orientations) adapt to diverse operational demands.
7. Tool-free opening angle adjustment via replacement of adjustment screws (15°-180° range).
Category: Welding Clamping Cylinders | Brand: AIRTAC | Series: JCK
AirTAC JCK Series Heavy-Duty Welding Clamping Cylinder JCK40X105AM1LKN
- Model: JCK40X105AM1LKN
- Type: Double-acting welded clamp cylinder
- Bore size: 40mm
- Stroke: 105mm
- Operating pressure: 0.1–0.8 MPa (14.5–116 PSI)
- Temperature range: -10℃ to 70℃ (14°F to 158°F)
- Port size: Rc1/4 (NPT1/4 optional)
- Cushioning: Adjustable rubber buffer + shock absorber pad
- Mounting type: Rectangular flange mounting (ISO 15552 standard)
- Rod material: Hard chrome-plated stainless steel
- Body material: Anodized aluminum alloy
- Seal type: HNBR seals with wear-resistant guide rings
- Protection rating: IP54 (standard dust/moisture resistance)
- Weight: 2.8 kg (6.17 lbs)
- Dimensions:
- Length (retracted): 254mm
- Extended length: 359mm
- Body width: 62mm
- Mounting height: 76mm
- Rod end thread: M20×1.5
Industrial-grade clamping cylinder specifically engineered for high vibration welding environments. Features enhanced lateral load capacity with dual guide rods and precision ground piston rods (Ra≤0.2μm surface finish). The reinforced welding structure withstands 500℃ intermittent heat exposure for 30 seconds. Includes magnetic switch grooves for sensor integration.
- Robotic welding fixture positioning in automotive assembly
- Heavy plate clamping for shipbuilding jigs
- Forging machine tool holding mechanisms
- High-frequency resistance welding equipment
- Precision sheet metal alignment systems
Installation guidelines:
Use lock nuts with 35-45 N·m torque specification during mounting.
Maintain 0.3-0.6 MPa lubrication pressure when using automatic lubricators.
For welding applications, install heat-resistant shield within 200mm radius.
| Property | Property Value |
|---|---|
| sku | JCK40X105AM1LKN |
| Clamping Arm Position Code | Clamping Arm Horizontal |
| Clamping Arm Model Code | Offset 15mm |
| Opening Angle | 105mm |
| Port Size | PT1/8 |
| Bore Diameter | <40mm> |
