Airtac JCK High Strength Welding Clamping Cylinder JCK40X105AM1RK
1. Patented crank-slider mechanism (constructed with high-strength, wear-resistant materials): a) Ensures structural stability and generates exceptional clamping force with minimal air pressure through high mechanical efficiency. b) Integrated self-locking mechanism maintains clamping force even during air supply interruption.
2. DIN-compliant four-side mounting configuration for flexible installation options.
3. Monolithic design integrating clamping mechanism with pneumatic cylinder for enhanced structural integrity.
4. Specially engineered sensor bracket with anti-spatter design and ±15° adjustable angles, featuring anti-interference shielding for stable signal transmission.
5. Space-efficient oval-shaped cylinder housing optimizes equipment layout in confined spaces.
6. Modular clamp arms (AM1/AM2/AM3/AM4) with R/C/L variants (radial/vertical/lateral orientations) adapt to diverse operational demands.
7. Tool-free opening angle adjustment via replacement of adjustment screws (15°-180° range).
Category: Welding Clamping Cylinders | Brand: AIRTAC | Series: JCK
AirTAC JCK Series Heavy-Duty Welded Clamping Cylinder JCK40X105AM1RK Technical Details
- Full Model: JCK40X105AM1RK (Standard type with reinforced structure)
- Bore Size: 40mm (ISO 6432 compliant)
- Stroke: 105mm (±0.5mm tolerance)
- Mounting Style: AM1 - Front flange mounting with through holes
- Operating Pressure: 0.1-0.9 MPa (14-130 PSI)
- Max Thrust: 1,130N @ 0.63MPa (Piston side)
- Piston Speed: 50-750 mm/s (lubricated condition)
- Port Size: G1/8 (BSPP thread)
- Cushioning: Adjustable rubber buffer (both ends)
- Ambient Temperature: -20℃ to 80℃ (NBR seals)
- Material:
- Tube: Hard-anodized aluminum alloy
- Piston Rod: Chrome-plated steel (HRC 45-50)
- End Caps: High-tensile cast aluminum
- Weight: 2.85 kg (with standard accessories)
- Dimensions:
- Extended Length: 255mm (stroke 105mm + base length)
- Retracted Length: 150mm
- Flange Mounting Base: 85mm × 55mm
- Rod End Thread: M16×1.5 (male)
- Protection Class: IP65 (wipers included)
- Certification: ISO 15552, RoHS compliant
Industrial-grade welding clamp cylinder featuring arc-resistant construction with triple-layer surface treatment (anodizing+chromating+powder coating). Optimized for high moment load applications through integrated guide reinforcement. The M1RK variant includes enhanced rod-lock mechanism for vertical operation security. Requires ISO VG32 hydraulic oil mist lubrication for optimal seal life.
- Robotic welding fixture positioning systems
- Stamping press blank holder force control
- Forging machine die clamping operations
- Automotive battery pack assembly jigs
- High-temperature foundry equipment
Installation Protocol:
Apply 22-25Nm torque to flange mounting bolts using cross-tightening sequence.
Maintain 0.05-0.15mm clearance between clamp jaws and cylinder axis.
Requires monthly inspection of rod wipers in particulate-heavy environments.
| Property | Property Value |
|---|---|
| sku | JCK40X105AM1RK |
| Clamping Arm Position Code | Clamping Arm Horizontal |
| Clamping Arm Model Code | Offset 15mm |
| Opening Angle | 105mm |
| Port Size | PT1/8 |
| Bore Diameter | <40mm> |
