Airtac JCK High Strength Welding Clamping Cylinder JCK40X105AM1RKN
$283.78
Regular price
$291.28
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
JCK40X105AM1RKN
Product type:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
JCK Heavy-duty Welding Clamp Cylinder
1. Patented crank-slider mechanism (constructed with high-strength, wear-resistant materials): a) Ensures structural stability and generates exceptional clamping force with minimal air pressure through high mechanical efficiency. b) Integrated self-locking mechanism maintains clamping force even during air supply interruption.
2. DIN-compliant four-side mounting configuration for flexible installation options.
3. Monolithic design integrating clamping mechanism with pneumatic cylinder for enhanced structural integrity.
4. Specially engineered sensor bracket with anti-spatter design and ±15° adjustable angles, featuring anti-interference shielding for stable signal transmission.
5. Space-efficient oval-shaped cylinder housing optimizes equipment layout in confined spaces.
6. Modular clamp arms (AM1/AM2/AM3/AM4) with R/C/L variants (radial/vertical/lateral orientations) adapt to diverse operational demands.
7. Tool-free opening angle adjustment via replacement of adjustment screws (15°-180° range).
Category: Welding Clamping Cylinders | Brand: AIRTAC | Series: JCK
Installation guidelines:
Use locknuts with torque ≤29.4N·m. Maintain 0.5mm minimum clearance between clamp arm and cylinder body during thermal expansion. For vertical mounting, install rod-end downward to prevent contamination accumulation.
1. Patented crank-slider mechanism (constructed with high-strength, wear-resistant materials): a) Ensures structural stability and generates exceptional clamping force with minimal air pressure through high mechanical efficiency. b) Integrated self-locking mechanism maintains clamping force even during air supply interruption.
2. DIN-compliant four-side mounting configuration for flexible installation options.
3. Monolithic design integrating clamping mechanism with pneumatic cylinder for enhanced structural integrity.
4. Specially engineered sensor bracket with anti-spatter design and ±15° adjustable angles, featuring anti-interference shielding for stable signal transmission.
5. Space-efficient oval-shaped cylinder housing optimizes equipment layout in confined spaces.
6. Modular clamp arms (AM1/AM2/AM3/AM4) with R/C/L variants (radial/vertical/lateral orientations) adapt to diverse operational demands.
7. Tool-free opening angle adjustment via replacement of adjustment screws (15°-180° range).
Category: Welding Clamping Cylinders | Brand: AIRTAC | Series: JCK
AirTAC JCK40X105AM1RKN Heavy-Duty Welded Clamping Cylinder Specifications
- Model: JCK40X105AM1RKN
- Bore size: 40mm
- Stroke: 105mm
- Mounting type: Front flange (AM1 series)
- Operating pressure: 0.1–0.8 MPa
- Piston rod material: Chrome-plated carbon steel (C45E)
- Tube material: Aluminum alloy with oxidation-resistant coating
- Cushioning: Adjustable rubber buffer (both ends)
- Port size: M5×0.8 (G1/8 adaptor included)
- Ambient temperature: -20℃ to 80℃
- Lubrication: Pre-lubricated (DOP oil compatible)
- Weight: 2.5kg (without accessories)
- Dimensions: 250mm(L) × 82mm(W) × 82mm(H)
- Rod thread: M10×1.25 external thread
- Repeat positioning accuracy: ±0.5mm
- ISO standard: 15552 compliant
High-rigidity welded cylinder designed for extreme clamping applications, featuring reinforced end caps and precision honed tube. The wear-resistant guide bushing ensures stable operation under heavy side loads. Special anti-spark construction makes it suitable for welding environments. Includes built-in magnet for position sensing compatibility.
Typical Applications:
- Robotic welding fixture systems
- Automotive frame jig clamping
- Forging press mold retention
- Heavy part positioning in CNC machining
- High-temperature foundry equipment
Installation guidelines:
Use locknuts with torque ≤29.4N·m. Maintain 0.5mm minimum clearance between clamp arm and cylinder body during thermal expansion. For vertical mounting, install rod-end downward to prevent contamination accumulation.
Maintenance:
Relubricate every 500km of stroke travel using ISO VG32 hydraulic oil. Inspect rod seals every 6 months in continuous operation. Replace cushion seals when impact velocity exceeds 0.5m/s.
| Property | Property Value |
|---|---|
| sku | JCK40X105AM1RKN |
| Clamping Arm Position Code | Clamping Arm Horizontal |
| Clamping Arm Model Code | Offset 15mm |
| Opening Angle | 105mm |
| Port Size | PT1/8 |
| Bore Diameter | <40mm> |
