Airtac JCK High Strength Welding Clamping Cylinder JCK40X105AM3C
$234.93
Regular price
$242.43
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
JCK40X105AM3C
Product type:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
JCK Heavy-duty Welding Clamp Cylinder
1. Patented crank-slider mechanism (constructed with high-strength, wear-resistant materials): a) Ensures structural stability and generates exceptional clamping force with minimal air pressure through high mechanical efficiency. b) Integrated self-locking mechanism maintains clamping force even during air supply interruption.
2. DIN-compliant four-side mounting configuration for flexible installation options.
3. Monolithic design integrating clamping mechanism with pneumatic cylinder for enhanced structural integrity.
4. Specially engineered sensor bracket with anti-spatter design and ±15° adjustable angles, featuring anti-interference shielding for stable signal transmission.
5. Space-efficient oval-shaped cylinder housing optimizes equipment layout in confined spaces.
6. Modular clamp arms (AM1/AM2/AM3/AM4) with R/C/L variants (radial/vertical/lateral orientations) adapt to diverse operational demands.
7. Tool-free opening angle adjustment via replacement of adjustment screws (15°-180° range).
Category: Welding Clamping Cylinders | Brand: AIRTAC | Series: JCK
Installation guidelines:
Maintain 0.5mm clearance between clamp arm and cylinder body during mounting.
Use locknuts with 20–25N·m torque specification. Requires 5μm filtered air supply
with auto-drainage function. Perform weekly lubrication checks in continuous operation.
1. Patented crank-slider mechanism (constructed with high-strength, wear-resistant materials): a) Ensures structural stability and generates exceptional clamping force with minimal air pressure through high mechanical efficiency. b) Integrated self-locking mechanism maintains clamping force even during air supply interruption.
2. DIN-compliant four-side mounting configuration for flexible installation options.
3. Monolithic design integrating clamping mechanism with pneumatic cylinder for enhanced structural integrity.
4. Specially engineered sensor bracket with anti-spatter design and ±15° adjustable angles, featuring anti-interference shielding for stable signal transmission.
5. Space-efficient oval-shaped cylinder housing optimizes equipment layout in confined spaces.
6. Modular clamp arms (AM1/AM2/AM3/AM4) with R/C/L variants (radial/vertical/lateral orientations) adapt to diverse operational demands.
7. Tool-free opening angle adjustment via replacement of adjustment screws (15°-180° range).
Category: Welding Clamping Cylinders | Brand: AIRTAC | Series: JCK
AirTAC JCK40X105AM3C Heavy-Duty Welding Clamping Cylinder Specifications
- Model: JCK40X105AM3C
- Type: Double-acting reinforced welding clamp cylinder
- Bore size: 40mm (ISO 6432 standard)
- Stroke: 105mm (±0.5mm tolerance)
- Operating pressure: 0.2–1.0 MPa
- Maximum thrust: 490N at 0.5MPa (push/pull)
- Piston speed: 50–700mm/s
- Operating temperature: -10℃ to 80℃
- Cushioning: Adjustable rubber buffer + impact ring
- Rod material: Hard chrome-plated stainless steel (SUS304)
- Tube material: Anodized aluminum alloy (AL6063-T5)
- Seal type: HNBR high-temperature seals
- Mounting style: M3 front flange with rear fixed pivot (ISO 15552)
- Weight: 2.85kg (without accessories)
- Dimensions: 235mm(L) × 62mm(W) × 62mm(H) (full extension)
- Port size: G1/8 (BSPP thread)
- Protection rating: IP54 (standard), IP67 optional
Industrial-grade clamping cylinder specifically engineered for high-vibration welding environments. Features enhanced structural integrity through multi-layer welding reinforcement and tungsten-treated piston rods. The M3C variant includes anti-spatter coating and magnetic switch grooves for position feedback integration.
Typical Applications:
- Robotic welding fixture systems (automotive frame assembly)
- High-temperature spot welding machines
- Press-fit component alignment in white goods manufacturing
- Forging press auxiliary clamping mechanisms
- Heavy-duty material handling grippers
Installation guidelines:
Maintain 0.5mm clearance between clamp arm and cylinder body during mounting.
Use locknuts with 20–25N·m torque specification. Requires 5μm filtered air supply
with auto-drainage function. Perform weekly lubrication checks in continuous operation.
| Property | Property Value |
|---|---|
| sku | JCK40X105AM3C |
| Clamping Arm Position Code | Clamping Arm Horizontal |
| Clamping Arm Model Code | Offset 45mm |
| Opening Angle | 105mm |
| Port Size | PT1/8 |
| Bore Diameter | <40mm> |
