Airtac JCK High Strength Welding Clamping Cylinder JCK40X105AM3CK
$283.78
Regular price
$291.28
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
JCK40X105AM3CK
Product type:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
JCK Heavy-duty Welding Clamp Cylinder
1. Patented crank-slider mechanism (constructed with high-strength, wear-resistant materials): a) Ensures structural stability and generates exceptional clamping force with minimal air pressure through high mechanical efficiency. b) Integrated self-locking mechanism maintains clamping force even during air supply interruption.
2. DIN-compliant four-side mounting configuration for flexible installation options.
3. Monolithic design integrating clamping mechanism with pneumatic cylinder for enhanced structural integrity.
4. Specially engineered sensor bracket with anti-spatter design and ±15° adjustable angles, featuring anti-interference shielding for stable signal transmission.
5. Space-efficient oval-shaped cylinder housing optimizes equipment layout in confined spaces.
6. Modular clamp arms (AM1/AM2/AM3/AM4) with R/C/L variants (radial/vertical/lateral orientations) adapt to diverse operational demands.
7. Tool-free opening angle adjustment via replacement of adjustment screws (15°-180° range).
Category: Welding Clamping Cylinders | Brand: AIRTAC | Series: JCK
Installation note:
Requires minimum 0.5μm filtered air with lubricator (ISO VG32 recommended).
For vertical mounting, use auxiliary guide mechanisms when handling asymmetric loads.
Torque limit: 35N·m on mounting bolts.
1. Patented crank-slider mechanism (constructed with high-strength, wear-resistant materials): a) Ensures structural stability and generates exceptional clamping force with minimal air pressure through high mechanical efficiency. b) Integrated self-locking mechanism maintains clamping force even during air supply interruption.
2. DIN-compliant four-side mounting configuration for flexible installation options.
3. Monolithic design integrating clamping mechanism with pneumatic cylinder for enhanced structural integrity.
4. Specially engineered sensor bracket with anti-spatter design and ±15° adjustable angles, featuring anti-interference shielding for stable signal transmission.
5. Space-efficient oval-shaped cylinder housing optimizes equipment layout in confined spaces.
6. Modular clamp arms (AM1/AM2/AM3/AM4) with R/C/L variants (radial/vertical/lateral orientations) adapt to diverse operational demands.
7. Tool-free opening angle adjustment via replacement of adjustment screws (15°-180° range).
Category: Welding Clamping Cylinders | Brand: AIRTAC | Series: JCK
AirTAC JCK40X105AM3CK Heavy-Duty Welding Clamping Cylinder Specifications
- Model: JCK40X105AM3CK
- Type: Double-acting welded cylinder with reinforced structure
- Bore size: 40mm
- Stroke: 105mm
- Port size: 1/4" NPT (G1/8 optional)
- Operating pressure: 0.1–0.9 MPa
- Cushioning: Adjustable pneumatic cushion at both ends
- Material: Aluminum alloy barrel, hardened stainless steel piston rod
- Seal material: High-temperature NBR seals
- Temperature range: -20℃ to 80℃
- Weight: 2.5kg (without accessories)
- Dimensions: 280mm(L) × 76mm(W) × 40mm(H) (maximum extended length)
- Mounting: Standard ISO 15552 front flange (MF1) with multiple accessory options
- Protection rating: IP65 (standard), IP67 available on request
- Rod thread: M20×1.5 external thread
- Max thrust: 503N at 0.6MPa
Industrial-grade clamping cylinder specifically engineered for high-load welding applications. Features precision-ground chrome piston rod with wear-resistant coating and anti-rotation mechanism. The reinforced welded construction withstands intense vibration and thermal stress in foundry environments. Includes magnetic piston for position sensing compatibility.
Typical Applications:
- Robotic welding fixture systems in automotive production
- High-frequency spot welding machine clamping
- Forging press tool holding mechanisms
- Heavy-duty metal stamping press positioning
- Foundry mold locking systems
Installation note:
Requires minimum 0.5μm filtered air with lubricator (ISO VG32 recommended).
For vertical mounting, use auxiliary guide mechanisms when handling asymmetric loads.
Torque limit: 35N·m on mounting bolts.
Service Interval:
- Relubricate every 500,000 cycles or 6 months
- Inspect rod seals every 200 operating hours in high-spatter environments
- Replace cushion seals at 1 million cycles
| Property | Property Value |
|---|---|
| sku | JCK40X105AM3CK |
| Clamping Arm Position Code | Clamping Arm Horizontal |
| Clamping Arm Model Code | Offset 45mm |
| Opening Angle | 105mm |
| Port Size | PT1/8 |
| Bore Diameter | <40mm> |
