Airtac JCK High Strength Welding Clamping Cylinder JCK40X105AM3CKA
$351.25
Regular price
$358.75
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
JCK40X105AM3CKA
Product type:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
JCK Heavy-duty Welding Clamp Cylinder
1. Patented crank-slider mechanism (constructed with high-strength, wear-resistant materials): a) Ensures structural stability and generates exceptional clamping force with minimal air pressure through high mechanical efficiency. b) Integrated self-locking mechanism maintains clamping force even during air supply interruption.
2. DIN-compliant four-side mounting configuration for flexible installation options.
3. Monolithic design integrating clamping mechanism with pneumatic cylinder for enhanced structural integrity.
4. Specially engineered sensor bracket with anti-spatter design and ±15° adjustable angles, featuring anti-interference shielding for stable signal transmission.
5. Space-efficient oval-shaped cylinder housing optimizes equipment layout in confined spaces.
6. Modular clamp arms (AM1/AM2/AM3/AM4) with R/C/L variants (radial/vertical/lateral orientations) adapt to diverse operational demands.
7. Tool-free opening angle adjustment via replacement of adjustment screws (15°-180° range).
Category: Welding Clamping Cylinders | Brand: AIRTAC | Series: JCK
Installation note:
Requires torque-controlled tightening (18-22 N·m for M8 mounting bolts).
Always install heat-resistant shielding sleeve (sold separately) when
operating above 100℃. Lubricate with ISO VG32 hydraulic oil.
Critical:
Avoid angular misalignment exceeding ±2° during installation.
Use only with compatible anti-vibration mounting brackets
(AIRTRM-40V2 recommended).
1. Patented crank-slider mechanism (constructed with high-strength, wear-resistant materials): a) Ensures structural stability and generates exceptional clamping force with minimal air pressure through high mechanical efficiency. b) Integrated self-locking mechanism maintains clamping force even during air supply interruption.
2. DIN-compliant four-side mounting configuration for flexible installation options.
3. Monolithic design integrating clamping mechanism with pneumatic cylinder for enhanced structural integrity.
4. Specially engineered sensor bracket with anti-spatter design and ±15° adjustable angles, featuring anti-interference shielding for stable signal transmission.
5. Space-efficient oval-shaped cylinder housing optimizes equipment layout in confined spaces.
6. Modular clamp arms (AM1/AM2/AM3/AM4) with R/C/L variants (radial/vertical/lateral orientations) adapt to diverse operational demands.
7. Tool-free opening angle adjustment via replacement of adjustment screws (15°-180° range).
Category: Welding Clamping Cylinders | Brand: AIRTAC | Series: JCK
AirTAC JCK40X105AM3CKA Heavy-Duty Welding Clamping Cylinder Specifications
- Model: JCK40X105AM3CKA
- Type: Double-acting reinforced welding clamp cylinder
- Bore size: 40mm
- Stroke: 105mm
- Operating pressure: 0.1-1.0 MPa
- Piston rod material: Hard chrome-plated carbon steel (Cr-Mo)
- Cylinder tube: Aluminum alloy with hard anodized finish
- Seal type: NBR (Nitrile) wear-resistant seals
- Mounting style: M3 front flange with reinforced mounting bolts
- Cushioning: Adjustable hydraulic shock absorber (both ends)
- Temperature range: -20℃ to 150℃ (peak resistance)
- Weight: 2.85 kg (dry, without accessories)
- Dimensions: 235mm(L) × 62mm(W) × 62mm(H) (fully retracted)
- Port size: G1/8 (BSPP thread)
- Rod end thread: M16×1.5
- Protection rating: IP54 (standard), IP67 optional
Industrial-grade clamping cylinder specifically engineered for high-vibration welding environments. Features triple-sealed construction with heat-resistant wiper rings to prevent spatter ingress. The reinforced rod gland utilizes tapered roller bearings for anti-rotation stability during high moment loads. Requires 5μm filtered air with 10-30% relative humidity.
Typical Applications:
- Robotic welding fixture systems in automotive assembly
- Resistance spot welding electrode actuation
- High-temperature metal stamping press clamping
- Foundry mold locking mechanisms
- Heavy-duty jig positioning in shipbuilding
Installation note:
Requires torque-controlled tightening (18-22 N·m for M8 mounting bolts).
Always install heat-resistant shielding sleeve (sold separately) when
operating above 100℃. Lubricate with ISO VG32 hydraulic oil.
Critical:
Avoid angular misalignment exceeding ±2° during installation.
Use only with compatible anti-vibration mounting brackets
(AIRTRM-40V2 recommended).
| Property | Property Value |
|---|---|
| sku | JCK40X105AM3CKA |
| Clamping Arm Position Code | Clamping Arm Horizontal |
| Clamping Arm Model Code | Offset 45mm |
| Opening Angle | 105mm |
| Port Size | PT1/8 |
| Bore Diameter | <40mm> |
