Airtac JCK High Strength Welding Clamping Cylinder JCK40X105AM3CKN
1. Patented crank-slider mechanism (constructed with high-strength, wear-resistant materials): a) Ensures structural stability and generates exceptional clamping force with minimal air pressure through high mechanical efficiency. b) Integrated self-locking mechanism maintains clamping force even during air supply interruption.
2. DIN-compliant four-side mounting configuration for flexible installation options.
3. Monolithic design integrating clamping mechanism with pneumatic cylinder for enhanced structural integrity.
4. Specially engineered sensor bracket with anti-spatter design and ±15° adjustable angles, featuring anti-interference shielding for stable signal transmission.
5. Space-efficient oval-shaped cylinder housing optimizes equipment layout in confined spaces.
6. Modular clamp arms (AM1/AM2/AM3/AM4) with R/C/L variants (radial/vertical/lateral orientations) adapt to diverse operational demands.
7. Tool-free opening angle adjustment via replacement of adjustment screws (15°-180° range).
Category: Welding Clamping Cylinders | Brand: AIRTAC | Series: JCK
AirTAC JCK Series Heavy-Duty Welding Clamp Cylinder JCK40X105AM3CKN
- Model: JCK40X105AM3CKN
- Type: Double-acting reinforced welding clamp cylinder
- Bore size: 40mm
- Stroke: 105mm
- Mounting type: Front flange with dual mounting holes (AM3)
- Operating pressure: 0.1–0.9 MPa
- Medium temperature: -20℃ to 80℃
- Cushioning: Adjustable pneumatic cushion (C designation)
- Piston rod material: Hard chrome-plated stainless steel
- Seal material: Heat-resistant NBR with wear ring
- Port size: M5x0.8 (standard), G1/8 optional
- Protection rating: IP40 (dust protected)
- Weight: 2.45kg ±3%
- Dimensions: 205mm(L) × 52mm(W) × 52mm(H)
- Accessories: Built-in magnet for sensor attachment (KN suffix)
Industrial-grade clamp cylinder specifically engineered for high-vibration welding environments. Features a reinforced welded body construction with 30% thicker cylinder walls compared to standard models. The chrome-silicon alloy piston rod resists spatter adhesion, while the triple-lip seal ensures leak-free operation even under lateral loads. Requires ISO 8573-1:2010 [4:4:4] compressed air quality.
- Robotic welding fixture clamping in automotive assembly
- High-temperature spot welding machine tooling
- Forging press positioning systems
- Heavy-part jigging in shipbuilding
- Injection mold locking during overmolding processes
Installation protocol:
Use M8 grade 8.8 mounting bolts with spring washers. Apply anti-seize compound
on piston rod threads. Perform 50-cycle break-in at 0.3MPa before full load operation.
Maintain monthly lubrication via integrated grease nipple (NLGI #2 lithium soap base).
| Property | Property Value |
|---|---|
| sku | JCK40X105AM3CKN |
| Clamping Arm Position Code | Clamping Arm Horizontal |
| Clamping Arm Model Code | Offset 45mm |
| Opening Angle | 105mm |
| Port Size | PT1/8 |
| Bore Diameter | <40mm> |
