Airtac JCK High Strength Welding Clamping Cylinder JCK40X105AM3L
1. Patented crank-slider mechanism (constructed with high-strength, wear-resistant materials): a) Ensures structural stability and generates exceptional clamping force with minimal air pressure through high mechanical efficiency. b) Integrated self-locking mechanism maintains clamping force even during air supply interruption.
2. DIN-compliant four-side mounting configuration for flexible installation options.
3. Monolithic design integrating clamping mechanism with pneumatic cylinder for enhanced structural integrity.
4. Specially engineered sensor bracket with anti-spatter design and ±15° adjustable angles, featuring anti-interference shielding for stable signal transmission.
5. Space-efficient oval-shaped cylinder housing optimizes equipment layout in confined spaces.
6. Modular clamp arms (AM1/AM2/AM3/AM4) with R/C/L variants (radial/vertical/lateral orientations) adapt to diverse operational demands.
7. Tool-free opening angle adjustment via replacement of adjustment screws (15°-180° range).
Category: Welding Clamping Cylinders | Brand: AIRTAC | Series: JCK
AirTAC JCK Series Heavy-Duty Welding Clamp Cylinder JCK40X105AM3L Specifications
- Model: JCK40X105AM3L
- Type: Double-acting welded clamp cylinder
- Bore diameter: 40mm
- Stroke: 105mm
- Operating pressure: 0.2–1.0 MPa
- Operating temperature: -10℃ to 80℃ (14℉ to 176℉)
- Port size: M5x0.8 (standard) with NPT1/8 adapter option
- Cushioning type: Adjustable buffer at both ends
- Mounting style: Front flange (M3 mounting holes) with reinforced base plate
- Piston rod material: Hard chrome-plated SCM435 steel
- Cylinder tube: Aluminum alloy with hard anodized finish
- Seal material: Heat-resistant NBR (Nitrile) + Polyurethane hybrid seals
- Weight: 1.65kg (3.64lbs) ±2%
- Dimensions: 212mm(L) × 56mm(W) × 56mm(H) (extended length)
- Retracted length: 107mm
- Rod thread: M10x1.25 external thread
- Lubrication: Pre-lubricated (Grease-free operation possible)
- ISO standard: Compliant with ISO 6432
Industrial-grade clamp cylinder specifically engineered for high rigidity welding applications. Features a reinforced welded structure with anti-spark coating, capable of withstanding 2x standard lateral loads. The M3L variant includes a thermal barrier sleeve for arc welding environments (up to 150℃ intermittent exposure). Requires 5μm filtered air with optional auto-lubricator compatibility.
- Robotic welding fixture positioning in automotive assembly
- High-temperature mold clamping for die casting
- Heavy-part immobilization in resistance spot welding
- CNC machining center workpiece locking
- Forge press auxiliary clamping systems
Installation note:
Use vibration-resistant locknuts (Class 8.8 or higher) for mounting.
Maintain 0.5-1mm clearance between clamp arm and cylinder body during thermal expansion.
Recommended cycle rate: ≤15 cycles/min for continuous welding applications.
| Property | Property Value |
|---|---|
| sku | JCK40X105AM3L |
| Clamping Arm Position Code | Clamping Arm Horizontal |
| Clamping Arm Model Code | Offset 45mm |
| Opening Angle | 105mm |
| Port Size | PT1/8 |
| Bore Diameter | <40mm> |
