Airtac JCK High Strength Welding Clamping Cylinder JCK40X105AM3LKA
$351.25
Regular price
$358.75
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
JCK40X105AM3LKA
Product type:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
JCK Heavy-duty Welding Clamp Cylinder
1. Patented crank-slider mechanism (constructed with high-strength, wear-resistant materials): a) Ensures structural stability and generates exceptional clamping force with minimal air pressure through high mechanical efficiency. b) Integrated self-locking mechanism maintains clamping force even during air supply interruption.
2. DIN-compliant four-side mounting configuration for flexible installation options.
3. Monolithic design integrating clamping mechanism with pneumatic cylinder for enhanced structural integrity.
4. Specially engineered sensor bracket with anti-spatter design and ±15° adjustable angles, featuring anti-interference shielding for stable signal transmission.
5. Space-efficient oval-shaped cylinder housing optimizes equipment layout in confined spaces.
6. Modular clamp arms (AM1/AM2/AM3/AM4) with R/C/L variants (radial/vertical/lateral orientations) adapt to diverse operational demands.
7. Tool-free opening angle adjustment via replacement of adjustment screws (15°-180° range).
Category: Welding Clamping Cylinders | Brand: AIRTAC | Series: JCK
Installation requirements:
Requires rigid mounting surface with flatness ≤0.1mm. Use anti-spatter coating on exposed surfaces when installed within 1.5m of welding arcs. Lubricate with ISO VG32 hydraulic oil during assembly. Perform alignment check every 500,000 cycles.
1. Patented crank-slider mechanism (constructed with high-strength, wear-resistant materials): a) Ensures structural stability and generates exceptional clamping force with minimal air pressure through high mechanical efficiency. b) Integrated self-locking mechanism maintains clamping force even during air supply interruption.
2. DIN-compliant four-side mounting configuration for flexible installation options.
3. Monolithic design integrating clamping mechanism with pneumatic cylinder for enhanced structural integrity.
4. Specially engineered sensor bracket with anti-spatter design and ±15° adjustable angles, featuring anti-interference shielding for stable signal transmission.
5. Space-efficient oval-shaped cylinder housing optimizes equipment layout in confined spaces.
6. Modular clamp arms (AM1/AM2/AM3/AM4) with R/C/L variants (radial/vertical/lateral orientations) adapt to diverse operational demands.
7. Tool-free opening angle adjustment via replacement of adjustment screws (15°-180° range).
Category: Welding Clamping Cylinders | Brand: AIRTAC | Series: JCK
AirTAC JCK Series Heavy-Duty Welding Clamp Cylinder JCK40X105AM3LKA Specifications
- Model: JCK40X105AM3LKA
- Bore size: 40mm
- Stroke: 105mm
- Operating pressure: 0.1–0.8 MPa
- Operating temperature: -20℃ to 80℃
- Port size: Rc1/4 (NPT1/4 optional)
- Cushioning: Adjustable rubber buffer + air cushion
- Mounting type: Front flange with reinforced gussets (ISO 15552 standard)
- Rod end: M16×1.5 external thread
- Material: Aluminum alloy barrel, chrome-plated piston rod
- Seal material: Heat-resistant NBR (up to 120℃ intermittent)
- Weight: 2.7kg (without accessories)
- Dimensions: 285mm(L) × 50mm(W) × 50mm(H) (retracted position)
- Protection rating: IP54 (standard), IP67 with optional wiper
- Accessories available: Magnetic switch (D-M9N), heat shield cover
Industrial-grade welding clamp cylinder engineered for high rigidity and thermal stability in harsh manufacturing environments. Features dual cushioning system with impact-absorbing structure, ideal for high-cycle clamping operations. The M3LKA variant includes enhanced rod locking mechanism for vertical load applications.
Typical Applications:
- Robotic welding fixture systems in automotive assembly
- High-temperature metal stamping press clamping
- Foundry mold locking mechanisms
- Heavy part positioning in battery pack assembly lines
- Forging machine tool workholding
Installation requirements:
Requires rigid mounting surface with flatness ≤0.1mm. Use anti-spatter coating on exposed surfaces when installed within 1.5m of welding arcs. Lubricate with ISO VG32 hydraulic oil during assembly. Perform alignment check every 500,000 cycles.
| Property | Property Value |
|---|---|
| sku | JCK40X105AM3LKA |
| Clamping Arm Position Code | Clamping Arm Horizontal |
| Clamping Arm Model Code | Offset 45mm |
| Opening Angle | 105mm |
| Port Size | PT1/8 |
| Bore Diameter | <40mm> |
