Airtac JCK High Strength Welding Clamping Cylinder JCK40X105AM3LKN
$283.78
Regular price
$291.28
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
JCK40X105AM3LKN
Product type:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
JCK Heavy-duty Welding Clamp Cylinder
1. Patented crank-slider mechanism (constructed with high-strength, wear-resistant materials): a) Ensures structural stability and generates exceptional clamping force with minimal air pressure through high mechanical efficiency. b) Integrated self-locking mechanism maintains clamping force even during air supply interruption.
2. DIN-compliant four-side mounting configuration for flexible installation options.
3. Monolithic design integrating clamping mechanism with pneumatic cylinder for enhanced structural integrity.
4. Specially engineered sensor bracket with anti-spatter design and ±15° adjustable angles, featuring anti-interference shielding for stable signal transmission.
5. Space-efficient oval-shaped cylinder housing optimizes equipment layout in confined spaces.
6. Modular clamp arms (AM1/AM2/AM3/AM4) with R/C/L variants (radial/vertical/lateral orientations) adapt to diverse operational demands.
7. Tool-free opening angle adjustment via replacement of adjustment screws (15°-180° range).
Category: Welding Clamping Cylinders | Brand: AIRTAC | Series: JCK
Installation protocol:
Use heat-resistant mounting hardware (class 8.8 or higher). Maintain 0.5mm clearance
between cylinder body and welding fixtures for thermal expansion. Apply anti-seize
compound on rod threads during high-temp installations.
1. Patented crank-slider mechanism (constructed with high-strength, wear-resistant materials): a) Ensures structural stability and generates exceptional clamping force with minimal air pressure through high mechanical efficiency. b) Integrated self-locking mechanism maintains clamping force even during air supply interruption.
2. DIN-compliant four-side mounting configuration for flexible installation options.
3. Monolithic design integrating clamping mechanism with pneumatic cylinder for enhanced structural integrity.
4. Specially engineered sensor bracket with anti-spatter design and ±15° adjustable angles, featuring anti-interference shielding for stable signal transmission.
5. Space-efficient oval-shaped cylinder housing optimizes equipment layout in confined spaces.
6. Modular clamp arms (AM1/AM2/AM3/AM4) with R/C/L variants (radial/vertical/lateral orientations) adapt to diverse operational demands.
7. Tool-free opening angle adjustment via replacement of adjustment screws (15°-180° range).
Category: Welding Clamping Cylinders | Brand: AIRTAC | Series: JCK
AirTAC JCK Series Heavy-Duty Welding Clamp Cylinder JCK40X105AM3LKN
- Model Decode: JCK40-X105-AM3L-KN
- Bore size: 40mm
- Stroke: 105mm
- Operating pressure: 0.05-1.0 MPa
- Action type: Double-acting
- Cushion type: Adjustable rubber buffer (both ends)
- Mounting style: MF2 front flange with integrated mounting holes
- Rod end: Female thread M16×1.5
- Piston material: Aluminum alloy with hard anodizing
- Rod material: Chrome-plated steel (Cr-Mo)
- Seal type: Heat-resistant NBR seals (up to 120℃)
- Ambient temperature: -10℃ to 80℃ (with high-temp seals)
- Port size: G1/8 (ISO228 standard)
- Position detection: Built-in magnetic sensor slot (M3 size)
- Weight: 1.65kg (without accessories)
- Dimensions: 208mm(L) × 58mm(W) × 58mm(H)
- Protection class: IP54 (standard wiper design)
- Lubrication: Pre-lubricated (Grease-free operation)
Heavy-wall cylinder specifically engineered for welding fixture applications, featuring enhanced heat deflection resistance and anti-spatter coating. The reinforced rod guide system ensures precise linear motion under high lateral loads. Includes built-in mounting bosses for welding jig integration.
Industrial Applications:
- Robotic welding positioners in automotive assembly
- High-temperature metal stamping fixtures
- Resistance welding electrode actuation
- Foundry equipment clamping mechanisms
- Forging machine tool positioning
Installation protocol:
Use heat-resistant mounting hardware (class 8.8 or higher). Maintain 0.5mm clearance
between cylinder body and welding fixtures for thermal expansion. Apply anti-seize
compound on rod threads during high-temp installations.
Special note:
Requires 5-20μm filtration with moisture separator. For continuous welding
applications, install thermal barrier shield (sold separately) when ambient
temperature exceeds 150℃ near heat zones.
| Property | Property Value |
|---|---|
| sku | JCK40X105AM3LKN |
| Clamping Arm Position Code | Clamping Arm Horizontal |
| Clamping Arm Model Code | Offset 45mm |
| Opening Angle | 105mm |
| Port Size | PT1/8 |
| Bore Diameter | <40mm> |
