Airtac JCK High Strength Welding Clamping Cylinder JCK40X105AM3RK
1. Patented crank-slider mechanism (constructed with high-strength, wear-resistant materials): a) Ensures structural stability and generates exceptional clamping force with minimal air pressure through high mechanical efficiency. b) Integrated self-locking mechanism maintains clamping force even during air supply interruption.
2. DIN-compliant four-side mounting configuration for flexible installation options.
3. Monolithic design integrating clamping mechanism with pneumatic cylinder for enhanced structural integrity.
4. Specially engineered sensor bracket with anti-spatter design and ±15° adjustable angles, featuring anti-interference shielding for stable signal transmission.
5. Space-efficient oval-shaped cylinder housing optimizes equipment layout in confined spaces.
6. Modular clamp arms (AM1/AM2/AM3/AM4) with R/C/L variants (radial/vertical/lateral orientations) adapt to diverse operational demands.
7. Tool-free opening angle adjustment via replacement of adjustment screws (15°-180° range).
Category: Welding Clamping Cylinders | Brand: AIRTAC | Series: JCK
AirTAC JCK Series Heavy-Duty Welding Clamp Cylinder JCK40X105AM3RK
- Model: JCK40X105AM3RK
- Bore size: 40mm
- Stroke: 105mm
- Mounting type: M3 reinforced square flange
- Operating pressure: 0.1–1.0 MPa
- Cushioning: Adjustable pneumatic cushion (dual-side)
- Seal material: Heat-resistant NBR (Nitrile Butadiene Rubber)
- Temperature range: -20℃ to 80℃
- Port size: G1/8 (ISO standard)
- Piston rod material: Hard chrome-plated steel (HCP)
- Max thrust: 1,256N @ 0.63MPa
- Max speed: 500–800 mm/s
- Protection rating: IP40
- Weight: 2.8kg (with standard accessories)
- Dimensions: 225mm(L) × 40mm(W) × 56mm(H)
Industrial-grade welding clamp cylinder engineered for high rigidity and thermal stability. Features anti-spatter coating (AS2 grade) and reinforced guide bearings for precision alignment under heavy loads. The M3 mounting flange incorporates 4xM8 threaded holes with vibration-resistant lock nuts. Requires 5μm filtered air with <0.1mg/m³ oil content.
- Robotic welding fixture systems
- High-temperature press brake tooling
- Automotive chassis assembly jigs
- Forging machine workpiece positioning
- Heavy part transfer in foundries
Installation protocol:
Apply thermal barrier paste (≥800℃ rating) between cylinder and welding fixture.
Maintain 15° maximum angular misalignment during mounting.
Pre-lubrication not required (maintenance-free design).
| Property | Property Value |
|---|---|
| sku | JCK40X105AM3RK |
| Clamping Arm Position Code | Clamping Arm Horizontal |
| Clamping Arm Model Code | Offset 45mm |
| Opening Angle | 105mm |
| Port Size | PT1/8 |
| Bore Diameter | <40mm> |
