Airtac JCK High Strength Welding Clamping Cylinder JCK40X105AM3RKA
1. Patented crank-slider mechanism (constructed with high-strength, wear-resistant materials): a) Ensures structural stability and generates exceptional clamping force with minimal air pressure through high mechanical efficiency. b) Integrated self-locking mechanism maintains clamping force even during air supply interruption.
2. DIN-compliant four-side mounting configuration for flexible installation options.
3. Monolithic design integrating clamping mechanism with pneumatic cylinder for enhanced structural integrity.
4. Specially engineered sensor bracket with anti-spatter design and ±15° adjustable angles, featuring anti-interference shielding for stable signal transmission.
5. Space-efficient oval-shaped cylinder housing optimizes equipment layout in confined spaces.
6. Modular clamp arms (AM1/AM2/AM3/AM4) with R/C/L variants (radial/vertical/lateral orientations) adapt to diverse operational demands.
7. Tool-free opening angle adjustment via replacement of adjustment screws (15°-180° range).
Category: Welding Clamping Cylinders | Brand: AIRTAC | Series: JCK
AirTAC JCK Heavy-Duty Welding Clamp Cylinder JCK40X105AM3RKA Specifications
- Model: JCK40X105AM3RKA
- Type: Double-acting welded clamping cylinder
- Bore size: 40mm
- Stroke: 105mm
- Operating pressure: 0.1–1.0 MPa
- Cushioning: Adjustable hydraulic shock absorber (both ends)
- Mounting type: M3X reinforced side mounting
- Port size: Rc1/8 (G1/8 optional)
- Piston rod material: Chrome-plated SCM435 steel
- Cylinder tube: Hard-anodized aluminum alloy
- Seal material: Heat-resistant NBR+PU hybrid
- Temperature range: -20℃ to 120℃ (peak 150℃ intermittent)
- Weight: 2.8kg ±3%
- Dimensions: 345mm(L) × 40mm(W) × 40mm(H)
- Rod thread: M12x1.75-6g
- Lateral load capacity: ≤250N
- Protection rating: IP67 (wipers included)
Industrial-grade clamping cylinder specifically engineered for high-temperature welding environments. Features a tungsten-reinforced piston rod tip for spark resistance and anti-rotation keyway design. Includes built-in magnet for position sensing compatibility. Requires 5μm filtered dry air with ISO VG32 lubricator oil mist.
- Robotic welding fixture positioning systems
- Automotive frame jig clamping
- High-frequency resistance welding machines
- Forging press mold retention
- Battery pack assembly thermal compression
Installation note:
Mount with 0.05mm/m alignment tolerance maximum. Apply copper-based anti-seize compound
on rod threads when operating above 80℃. Perform weekly lubrication checks in continuous
welding applications.
| Property | Property Value |
|---|---|
| sku | JCK40X105AM3RKA |
| Clamping Arm Position Code | Clamping Arm Horizontal |
| Clamping Arm Model Code | Offset 45mm |
| Opening Angle | 105mm |
| Port Size | PT1/8 |
| Bore Diameter | <40mm> |
