Airtac JCK High Strength Welding Clamping Cylinder JCK40X105AM3RKN
$283.78
Regular price
$291.28
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
JCK40X105AM3RKN
Product type:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
JCK Heavy-duty Welding Clamp Cylinder
1. Patented crank-slider mechanism (constructed with high-strength, wear-resistant materials): a) Ensures structural stability and generates exceptional clamping force with minimal air pressure through high mechanical efficiency. b) Integrated self-locking mechanism maintains clamping force even during air supply interruption.
2. DIN-compliant four-side mounting configuration for flexible installation options.
3. Monolithic design integrating clamping mechanism with pneumatic cylinder for enhanced structural integrity.
4. Specially engineered sensor bracket with anti-spatter design and ±15° adjustable angles, featuring anti-interference shielding for stable signal transmission.
5. Space-efficient oval-shaped cylinder housing optimizes equipment layout in confined spaces.
6. Modular clamp arms (AM1/AM2/AM3/AM4) with R/C/L variants (radial/vertical/lateral orientations) adapt to diverse operational demands.
7. Tool-free opening angle adjustment via replacement of adjustment screws (15°-180° range).
Category: Welding Clamping Cylinders | Brand: AIRTAC | Series: JCK
Installation notes:
1. Patented crank-slider mechanism (constructed with high-strength, wear-resistant materials): a) Ensures structural stability and generates exceptional clamping force with minimal air pressure through high mechanical efficiency. b) Integrated self-locking mechanism maintains clamping force even during air supply interruption.
2. DIN-compliant four-side mounting configuration for flexible installation options.
3. Monolithic design integrating clamping mechanism with pneumatic cylinder for enhanced structural integrity.
4. Specially engineered sensor bracket with anti-spatter design and ±15° adjustable angles, featuring anti-interference shielding for stable signal transmission.
5. Space-efficient oval-shaped cylinder housing optimizes equipment layout in confined spaces.
6. Modular clamp arms (AM1/AM2/AM3/AM4) with R/C/L variants (radial/vertical/lateral orientations) adapt to diverse operational demands.
7. Tool-free opening angle adjustment via replacement of adjustment screws (15°-180° range).
Category: Welding Clamping Cylinders | Brand: AIRTAC | Series: JCK
AirTAC JCK Heavy-Duty Welding Clamping Cylinder JCK40X105AM3RKN Specifications
- Model: JCK40X105AM3RKN
- Type: Double-acting welded rod cylinder with magnetic sensor slot
- Bore size: 40mm
- Stroke: 105mm (±0.5mm tolerance)
- Operating pressure: 0.05–1.0 MPa
- Operating temperature: -10℃ to 70℃ (no freeze)
- Cushioning: Adjustable rubber buffer + impact absorber
- Mounting style: Foot-mounted (ISO 15552 standard)
- Port size: PT1/4 (G1/4 optional)
- Rod material: Hard chrome-plated steel (3-5μm coating)
- Tube material: Anodized aluminum alloy (6063-T5)
- Seal material: Heat-resistant NBR (with anti-spatter coating)
- Weight: 2.3kg (with standard accessories)
- Dimensions: 275mm(L) × 62mm(W) × 62mm(H) (retracted position)
- Sensor compatibility: M3 slot for inductive proximity switches
- Protection rating: IP67 (wipers included)
Industrial-grade clamping cylinder engineered for high-moment resistance in welding environments. Features a reinforced rod guide system (triple lip seals) and anti-rotation piston rod. The special PTFE-impregnated rod coating resists welding spatter adhesion. Requires 5μm filtered air with <30% relative humidity.
Typical Applications:
- Robotic welding fixture systems
- Automotive chassis component clamping
- Heavy part positioning in foundries
- Press brake tooling securement
- Forging machine workholding
Installation notes:
- Mount using M8x1.25 screws (25Nm torque limit)
- Maintain 0.5-1mm clearance between magnetic sensor and slot
- Apply high-temperature grease (≥200℃ rating) to rod weekly in continuous operation
- Use 2:1 lever ratio for optimal clamping force distribution
| Property | Property Value |
|---|---|
| sku | JCK40X105AM3RKN |
| Clamping Arm Position Code | Clamping Arm Horizontal |
| Clamping Arm Model Code | Offset 45mm |
| Opening Angle | 105mm |
| Port Size | PT1/8 |
| Bore Diameter | <40mm> |
