Airtac JCK High Strength Welding Clamping Cylinder JCK40X105KA
$316.35
Regular price
$323.85
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
JCK40X105KA
Product type:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
JCK Heavy-duty Welding Clamp Cylinder
1. Patented crank-slider mechanism (constructed with high-strength, wear-resistant materials): a) Ensures structural stability and generates exceptional clamping force with minimal air pressure through high mechanical efficiency. b) Integrated self-locking mechanism maintains clamping force even during air supply interruption.
2. DIN-compliant four-side mounting configuration for flexible installation options.
3. Monolithic design integrating clamping mechanism with pneumatic cylinder for enhanced structural integrity.
4. Specially engineered sensor bracket with anti-spatter design and ±15° adjustable angles, featuring anti-interference shielding for stable signal transmission.
5. Space-efficient oval-shaped cylinder housing optimizes equipment layout in confined spaces.
6. Modular clamp arms (AM1/AM2/AM3/AM4) with R/C/L variants (radial/vertical/lateral orientations) adapt to diverse operational demands.
7. Tool-free opening angle adjustment via replacement of adjustment screws (15°-180° range).
Category: Welding Clamping Cylinders | Brand: AIRTAC | Series: JCK
Installation note:
For welding environments, install protective bellows (sold separately) to prevent spatter accumulation.
Lubricate pivot points every 500,000 cycles using ISO VG32 hydraulic oil. Maintain 0.5mm minimum clearance
between cylinder body and welding area. Use 40μm filtration to extend seal life.
1. Patented crank-slider mechanism (constructed with high-strength, wear-resistant materials): a) Ensures structural stability and generates exceptional clamping force with minimal air pressure through high mechanical efficiency. b) Integrated self-locking mechanism maintains clamping force even during air supply interruption.
2. DIN-compliant four-side mounting configuration for flexible installation options.
3. Monolithic design integrating clamping mechanism with pneumatic cylinder for enhanced structural integrity.
4. Specially engineered sensor bracket with anti-spatter design and ±15° adjustable angles, featuring anti-interference shielding for stable signal transmission.
5. Space-efficient oval-shaped cylinder housing optimizes equipment layout in confined spaces.
6. Modular clamp arms (AM1/AM2/AM3/AM4) with R/C/L variants (radial/vertical/lateral orientations) adapt to diverse operational demands.
7. Tool-free opening angle adjustment via replacement of adjustment screws (15°-180° range).
Category: Welding Clamping Cylinders | Brand: AIRTAC | Series: JCK
AirTAC JCK Series Heavy-Duty Welding Clamping Cylinder JCK40X105KA
- Model: JCK40X105KA
- Type: Double-acting welded cylinder (reinforced structure)
- Bore size: 40mm
- Stroke: 105mm
- Operating pressure: 0.1–0.9 MPa
- Operating temperature: -20℃ to 80℃ (NBR seals)
- Cushioning: Adjustable hydraulic buffer
- Mounting: Front flange (ISO 15552 standard)
- Material: Aluminum alloy barrel / Hard chrome-plated piston rod
- Weight: ~2.2kg (excluding accessories)
- Dimensions: 200mm(L) × 80mm(W) × 80mm(H) (at full retraction)
- Port size: G1/8 (standard industrial thread)
- Protection rating: IP54 (standard) / IP67 (optional wiper upgrade)
- Max thrust: 510N @0.6MPa
- Piston speed: 50–800mm/s
Robust welding-specific cylinder with reinforced welded construction for high rigidity in extreme conditions. Features heat-resistant seals (up to 120℃ intermittent) and anti-spatter coating on exposed surfaces. The integrated buffer mechanism reduces impact noise by 30% compared to standard models.
Typical Applications:
- Robotic welding fixture clamping in automotive production lines
- High-temperature metal stamping press positioning
- Foundry equipment mold locking systems
- Heavy-duty CNC plasma cutting machine tool fixation
- Battery pack assembly pressurization in EV manufacturing
Installation note:
For welding environments, install protective bellows (sold separately) to prevent spatter accumulation.
Lubricate pivot points every 500,000 cycles using ISO VG32 hydraulic oil. Maintain 0.5mm minimum clearance
between cylinder body and welding area. Use 40μm filtration to extend seal life.
| Property | Property Value |
|---|---|
| sku | JCK40X105KA |
| Clamping Arm Position Code | Clamping Arm Horizontal |
| Clamping Arm Model Code | Without Clamping Arm |
| Opening Angle | 105mm |
| Port Size | PT1/8 |
| Bore Diameter | <40mm> |
