Airtac JCK High Strength Welding Clamping Cylinder JCK40X105KN
1. Patented crank-slider mechanism (constructed with high-strength, wear-resistant materials): a) Ensures structural stability and generates exceptional clamping force with minimal air pressure through high mechanical efficiency. b) Integrated self-locking mechanism maintains clamping force even during air supply interruption.
2. DIN-compliant four-side mounting configuration for flexible installation options.
3. Monolithic design integrating clamping mechanism with pneumatic cylinder for enhanced structural integrity.
4. Specially engineered sensor bracket with anti-spatter design and ±15° adjustable angles, featuring anti-interference shielding for stable signal transmission.
5. Space-efficient oval-shaped cylinder housing optimizes equipment layout in confined spaces.
6. Modular clamp arms (AM1/AM2/AM3/AM4) with R/C/L variants (radial/vertical/lateral orientations) adapt to diverse operational demands.
7. Tool-free opening angle adjustment via replacement of adjustment screws (15°-180° range).
Category: Welding Clamping Cylinders | Brand: AIRTAC | Series: JCK
AirTAC JCK High-Force Welding Clamping Cylinder JCK40X105KN Technical Details
- Model: JCK40X105KN
- Type: Heavy-duty welded clamping cylinder (double-acting)
- Bore size: 40 mm
- Stroke: 105 mm
- Operating pressure: 0.1–0.8 MPa
- Max clamping force: 628 N (at 0.5 MPa)
- Port size: G1/8 (ISO228 standard)
- Cushioning type: Adjustable rubber buffer + fixed cushion pad
- Mounting style: Fixed rectangular base with 4x M6 threaded holes
- Temperature range: -10℃ to 150℃ (special high-temp seals)
- Seal material: Heat-resistant NBR + metal scrap wiper ring
- Protection rating: IP67 (wipers prevent slag ingress)
- Weight: 2.8 kg ±3%
- Dimensions: 300mm(L) × 58mm(W) × 58mm(H) (extended length)
Industrial-grade clamping cylinder engineered for robotic welding stations and high-vibration environments. Features laser-welded stainless steel construction with anti-spatter coating (5-8μm thickness). Integrated heat deflection plates protect seals from weld splatter up to 1,200℃ intermittent exposure. Requires 25μm filtered air with <0.5% relative humidity.
- Automotive chassis spot welding fixtures
- CNC plasma cutting table material clamping
- Press brake tooling alignment systems
- Battery pack assembly line welding robots
- Forging machine die positioning
Installation note:
Align within 0.2mm perpendicular tolerance during mounting. Apply Molykote G-4502 grease
quarterly. Use shock absorbers when cycle rate exceeds 120 CPM.
| Property | Property Value |
|---|---|
| sku | JCK40X105KN |
| Clamping Arm Position Code | Clamping Arm Horizontal |
| Clamping Arm Model Code | Without Clamping Arm |
| Opening Angle | 105mm |
| Port Size | PT1/8 |
| Bore Diameter | <40mm> |
