Airtac JCK High Strength Welding Clamping Cylinder JCK40X120AM1C
1. Patented crank-slider mechanism (constructed with high-strength, wear-resistant materials): a) Ensures structural stability and generates exceptional clamping force with minimal air pressure through high mechanical efficiency. b) Integrated self-locking mechanism maintains clamping force even during air supply interruption.
2. DIN-compliant four-side mounting configuration for flexible installation options.
3. Monolithic design integrating clamping mechanism with pneumatic cylinder for enhanced structural integrity.
4. Specially engineered sensor bracket with anti-spatter design and ±15° adjustable angles, featuring anti-interference shielding for stable signal transmission.
5. Space-efficient oval-shaped cylinder housing optimizes equipment layout in confined spaces.
6. Modular clamp arms (AM1/AM2/AM3/AM4) with R/C/L variants (radial/vertical/lateral orientations) adapt to diverse operational demands.
7. Tool-free opening angle adjustment via replacement of adjustment screws (15°-180° range).
Category: Welding Clamping Cylinders | Brand: AIRTAC | Series: JCK
AirTAC JCK Series Heavy-Duty Welding Clamping Cylinder JCK40X120AM1C
- Model: JCK40X120AM1C
- Type: Double-acting welded clamping cylinder
- Bore size: 40mm
- Stroke: 120mm (±0.5mm tolerance)
- Operating pressure: 0.05-1.0 MPa
- Mounting style: Front flange (ISO 15552 standard)
- Cushioning: Adjustable pneumatic cushion (both ends)
- Piston rod material: Chrome-plated stainless steel (SUS304)
- Tube material: Hard-anodized aluminum alloy
- Seals: NBR wear-resistant seals
- Port size: G1/8 (ISO standard thread)
- Ambient temperature: -20℃ to 80℃ (continuous operation)
- Max thrust: 502N @ 0.63MPa
- Weight: 2.65kg (without accessories)
- Dimensions: 202mm(L) × 58mm(W) × 58mm(H)
- Repeat positioning accuracy: ±0.2mm
- Sensor compatibility: Built-in magnet for magnetic switch (D-A93 series compatible)
Industrial-grade clamping cylinder specifically engineered for high-vibration welding environments. Features triple chrome plating on piston rods and tungsten-treated surfaces for spark resistance. The reinforced end caps incorporate heat-resistant seals capable of withstanding intermittent welding spatter up to 150℃. Includes anti-rotation guide slots for precise fixturing.
- Robotic welding jigs in automotive assembly lines
- Spot welding machine electrode clamping
- Metal fabrication press brake tooling
- Forging equipment workpiece positioning
- Battery module compression during laser welding
Installation guidelines:
Maintain 0.5-1mm clearance between cylinder body and welding surfaces.
Use copper-based anti-seize compound on threads when installing in ferrous materials.
Requires 5μm filtration with water separator for optimal seal life.
| Property | Property Value |
|---|---|
| sku | JCK40X120AM1C |
| Clamping Arm Position Code | Clamping Arm Horizontal |
| Clamping Arm Model Code | Offset 15mm |
| Opening Angle | 120mm |
| Port Size | PT1/8 |
| Bore Diameter | <40mm> |
