Airtac LGC Series Cross Roller Guide Rail LGC1A20R6-H
Category: Linear Guides , Brand: AirTAC , Series: LGC
AirTAC LGC Crossed Roller Guide LGC1A20R6-H Technical Specifications
- Model: LGC1A20R6-H
- Type: Precision crossed roller linear guide
- Rail width: 20mm
- Roller diameter: 6mm
- Dynamic load capacity (C): 3,200N (radial), 2,800N (reverse radial)
- Static load capacity (C0): 5,600N (radial), 4,900N (reverse radial)
- Accuracy grade: Normal (N) / High precision (H) options
- Preload levels: Light (Z0), Medium (Z1), Heavy (Z2)
- Material: High carbon chromium bearing steel (SUJ2 equivalent)
- Hardness: 58-62 HRC raceway surface
- Sealing: Triple labyrinth seal with stainless steel scrapers
- Lubrication: Pre-packed lithium complex grease
- Temperature range: -20℃ to 100℃
- Protection rating: IP65 (standard seals)
- Weight per unit length: 1.8kg/m
- Standard carriage dimensions: 42mm(W) × 34mm(H) × [Length varies]
- Rail height: 20mm
Ultra-precision crossed roller guide featuring 45° contact angle design for simultaneous radial and axial load capacity. The alternating orthogonal roller arrangement achieves near-zero clearance motion with ≤3μm repeatability. Hardened raceways and optimized roller crowning prevent edge stress concentration. Includes integrated oil reservoirs in carriage for extended maintenance intervals.
- High-speed CNC grinding machine Z-axis positioning
- Semiconductor wafer inspection stages
- 5-axis robotic arm rotary joints
- Optical lens coating equipment
- Coordinate measuring machine (CMM) slides
- Medical CT scanner gantry systems
Installation requirements:
Requires mounting surface flatness ≤0.01mm/m and roughness Ra0.8.
Use torque wrench for 2-step tightening sequence (50% → 100% of 8.8Nm).
Avoid side mounting without vertical support structure.
| Property | Property Value |
|---|---|
| sku | LGC1A20R6-H |
| Roller Outer Diameter | 1.5mm |
| Type | Three-column |
