Airtac LGC Series Cross Roller Guide Rail LGC1A20R7-H
Category: Linear Guides , Brand: AirTAC , Series: LGC
AirTAC LGC Crossed Roller Guide LGC1A20R7-H Technical Specifications
- Model: LGC1A20R7-H
- Series: Precision Crossed Roller Guide
- Rail width: 20mm
- Roller diameter: φ3.5mm (high-density chromium steel)
- Preload class: H-grade (medium preload)
- Dynamic load capacity: 12.5kN
- Static load capacity: 24.8kN
- Accuracy grade: P5 (≤5μm/100mm running parallelism)
- Standard rail length options: 300/500/1000/1500mm (customizable)
- Carriage dimensions: 76mm(L) × 34mm(W) × 23mm(H)
- Weight per 100mm rail: 0.68kg
- Mounting hole pattern: M5×8 counterbored, 40mm pitch
- Surface treatment: Black oxide coating (Fe3O4)
- Operating temperature: -15℃ to 80℃
- Lubrication: Pre-packed grease (relubrication interval: 1000km)
Ultra-precision linear motion system featuring crossed cylindrical rollers arranged at 90° angles, delivering exceptional stiffness and minimal elastic deformation under multi-directional loads. The optimized roller recirculation design ensures smooth motion with ≤0.003mm/m repeatability. Includes integrated wipers and grease ports for maintenance.
- High-speed CNC grinding machine Z-axis guidance
- Semiconductor wafer handling robots
- Coordinate measuring machine (CMM) stages
- Precision optical alignment systems
- Lithography equipment positioning
Installation guidelines:
Mount on ground reference surfaces with flatness ≤0.01mm/m.
Use 4.2Nm torque for M5 mounting screws with Loctite 243.
Avoid welding sparks and grinding debris contamination.
| Property | Property Value |
|---|---|
| sku | LGC1A20R7-H |
| Roller Outer Diameter | 1.5mm |
| Type | Three-column |
