Airtac LGC Series Cross Roller Guide Rail LGC1A30R10-H
Category: Linear Guides , Brand: AirTAC , Series: LGC
AirTAC LGC Crossed Roller Guide LGC1A30R10-H Technical Specifications
- Model: LGC1A30R10-H
- Type: Precision crossed roller linear guide
- Rail width: 30mm
- Roller diameter: 10mm (±0.002mm tolerance)
- Standard length options: 300/500/1000/1500mm (customizable)
- Dynamic load capacity: 10kN (C)
- Static load capacity: 15kN (C0)
- Precision grade: P5 (Running parallelism: ±0.01mm/1000mm)
- Height variation: ±0.005mm between multiple blocks
- Material: High-carbon chromium bearing steel (SUJ2 equivalent)
- Surface treatment: Black oxide coating + anti-corrosion oil
- Weight: 0.85kg per 100mm length (4.25kg for 500mm unit)
- Dimensions (W×H×L): 40mm × 30mm × [custom length]
- Operating temperature: -20℃ to 100℃
- Preload level: Medium preload (3-5% of C)
- Mounting hole pattern: M6 threaded holes @ 60mm pitch
Ultra-precision crossed roller guide system featuring high moment load resistance and near-zero backlash. The LGC series utilizes alternating orthogonal cylindrical rollers in a V-groove configuration for exceptional stiffness (3x higher than ball-type guides). Includes integrated sealing strips with wiper functionality for particle exclusion.
- High-precision CNC rotary tables and indexers
- Semiconductor wafer handling robots
- Medical CT scanner gantry systems
- Optical alignment stages for laser processing
- 5-axis machining center swivel heads
Installation criticals:
Requires mounting surface flatness ≤0.01mm/m and parallelism ≤0.02mm between rails.
Apply lithium complex grease (NLGI #2) during assembly. Avoid side hammering - use
press-fit tools for block installation.
| Property | Property Value |
|---|---|
| sku | LGC1A30R10-H |
| Roller Outer Diameter | 1.5mm |
| Type | Three-column |
