Airtac LGC Series Cross Roller Guide Rail LGC1A30R11-H
Category: Linear Guides , Brand: AirTAC , Series: LGC
AirTAC LGC Series Cross Roller Guide LGC1A30R11-H Technical Details
- Model: LGC1A30R11-H
- Type: Precision cross roller linear guide
- Rail width: 30mm
- Roller diameter: φ3.5mm (chrome steel)
- Preload level: Medium preload (C3 grade)
- Dynamic load capacity (radial): 12.5kN
- Static load capacity (radial): 24.3kN
- Accuracy class: High precision (H grade, ±0.005mm/300mm)
- Number of blocks: 1 carriage unit
- Sealing: Triple labyrinth seal + grease nipple
- Mounting hole spacing: 60mm longitudinal pitch
- Operating temperature: -20℃ to 100℃
- Lubrication: Pre-lubed with VIGO grease (relubrication every 1,000km travel)
- Weight per 100mm rail: 1.45kg (rail only) / 0.88kg (carriage)
- Dimensions (L×W×H):
- Standard rail length: 100-4000mm (customizable)
- Carriage size: 72mm(L) × 45mm(W) × 30mm(H)
- Rail height: 30mm
Engineered for ultra-precise linear motion systems requiring minimal deflection, the LGC1A30R11-H features staggered 90° angular contact rollers that eliminate clearance while maintaining smooth motion. Its hardened stainless steel raceway (HRC58+) ensures extended service life in contaminated environments. The optimized roller path geometry reduces edge stress concentration by 40% compared to conventional designs.
- High-speed CNC grinding machine Z-axis guidance
- Semiconductor wafer handling robots
- Coordinate measuring machine (CMM) stages
- Precision optical alignment systems
- Lithography equipment linear stages
Mounting protocol:
Requires surface flatness ≤0.01mm/m and parallelism ≤0.02mm between rails.
Tighten mounting bolts in crisscross pattern at 8.8Nm torque. Avoid exposing
to cutting fluids without protective covers.
| Property | Property Value |
|---|---|
| sku | LGC1A30R11-H |
| Roller Outer Diameter | 1.5mm |
| Type | Three-column |
