Airtac LGC Series Cross Roller Guide Rail LGC1A30R8-H
Category: Linear Guides , Brand: AirTAC , Series: LGC
AirTAC LGC Crossed Roller Guide LGC1A30R8-H Technical Specifications
- Model: LGC1A30R8-H
- Type: Precision crossed roller linear guide
- Rail width: 30mm
- Roller diameter: 8mm
- Preload level: Medium (C3 grade)
- Dynamic load capacity: 12.5kN
- Static load capacity: 24.8kN
- Accuracy class: Normal grade (±50μm/1000mm)
- Repeat positioning accuracy: ±0.005mm
- Roller material: GCr15 bearing steel (HRC 60-65)
- Rail material: Carbon steel with black oxide coating
- Sealing: Triple labyrinth seal with grease retention
- Temperature range: -20℃ to 100℃
- Weight per meter: 3.8kg/m
- Standard lengths: 500-2000mm (customizable)
- Cross-section dimensions: 30mm(W) × 27mm(H)
High-rigidity crossed roller guide featuring X-axis/Y-axis integrated design with 45° contact angle rollers. Provides exceptional moment load resistance and vibration damping through its unique alternating roller arrangement. Includes pre-loaded rollers for zero-backlash operation in bidirectional applications.
- High-precision CNC rotary tables
- Optical measurement equipment stages
- Semiconductor wafer handling robots
- Medical CT scanner gantries
- 5-axis machining center swivel heads
Mounting recommendation:
Apply M4×8 mounting screws at 60mm intervals with 6.5Nm torque.
Use granite surface plate for alignment (flatness ≤0.01mm/m).
Run-in with ISO VG32 grease for 30 minutes before full load operation.
| Property | Property Value |
|---|---|
| sku | LGC1A30R8-H |
| Roller Outer Diameter | 1.5mm |
| Type | Three-column |
