Airtac LGC Series Cross Roller Guide Rail LGC1A30R9-H
Category: Linear Guides , Brand: AirTAC , Series: LGC
AirTAC LGC Crossed Roller Guide LGC1A30R9-H Technical Details
- Model: LGC1A30R9-H
- Series: LGC (High Rigidity Crossed Roller Series)
- Rail Width: 30mm
- Roller Diameter: φ4.762mm (3/16")
- Preload Class: H (Heavy Preload)
- Dynamic Load Capacity (C): 12.5kN
- Static Load Capacity (C0): 26.8kN
- Accuracy Grade: P5 (High Precision)
- Max Travel Speed: 5m/s
- Operating Temperature: -20℃ to 100℃
- Lubrication: Grease-filled polymer retainers
- Sealing: Triple labyrinth seal with stainless steel scrapers
- Material: Induction-hardened S55C steel (HRC58+)
- Weight: 3.2kg/m (linear density)
- Standard Length Options: 500/1000/1500mm (customizable)
- Cross Section Dimensions: 30mm(W) × 24mm(H)
Precision linear motion system featuring 90° crossed cylindrical rollers for simultaneous load bearing in all directions. The hardened steel construction and heavy preload design deliver ±15μm/m positioning repeatability, with corrosion-resistant nickel plating (8-12μm thickness) for harsh environments.
- CNC coordinate measuring machines (CMM)
- Semiconductor wafer handling robots
- High-speed laser cutting X-Y stages
- Precision optical alignment systems
- Medical CT scanner gantry movement
Mounting requirements:
Requires surface flatness ≤0.01mm/m and mounting torque of 12-15N·m for M5 mounting screws.
Avoid angular misalignment exceeding ±0.5° during installation.
| Property | Property Value |
|---|---|
| sku | LGC1A30R9-H |
| Roller Outer Diameter | 1.5mm |
| Type | Three-column |
