Airtac LGC Series Cross Roller Guide Rail LGC1A40R11-H
Category: Linear Guides , Brand: AirTAC , Series: LGC
AirTAC LGC Crossed Roller Guide LGC1A40R11-H Technical Specifications
- Model: LGC1A40R11-H
- Series: LGC (High Rigidity Crossed Roller Series)
- Rail Width: 40mm
- Roller Diameter: 3.5mm (high-density chromium steel)
- Preload Class: Medium preload (C2 grade)
- Dynamic Load Capacity: 12.5kN
- Static Load Capacity: 24.8kN
- Accuracy Grade: P5 (≤5μm/1000mm running parallelism)
- Material: S55C carbon steel rail with black oxide coating
- Sealing: Triple labyrinth seal + stainless steel scrapers
- Lubrication: Pre-lubricated with ARDROX 3072 grease
- Operating Temperature: -20℃ to 100℃
- Weight: 3.8kg per 1000mm length
- Dimensions (per 1000mm section):
- Height: 34mm
- Width: 40mm
- Mounting Hole Spacing: 60mm pitch (M6 threaded holes)
Precision crossed roller guide with X-axis/Y-axis bidirectional rigidity, featuring 45° V-groove roller arrangement for moment load resistance. The hardened raceway surface (HRC 58-62) ensures extended service life under high-frequency reciprocation. Integrated dust-proof design meets ISO 14644-1 Class 5 cleanroom requirements.
- Semiconductor wafer handling robots
- 5-axis CNC rotary tables
- High-precision coordinate measuring machines
- Medical CT scanner gantries
- Lithography equipment linear stages
Installation requirements:
Base mounting surface flatness ≤0.01mm/m, roughness Ra1.6.
Apply 680-750N·m torque for M6 mounting screws using sequential
tightening pattern. Relubricate every 100km travel or 6 months.
| Property | Property Value |
|---|---|
| sku | LGC1A40R11-H |
| Roller Outer Diameter | 1.5mm |
| Type | Three-column |
