Airtac LGC Series Cross Roller Guide Rail LGC1A40R13-H
Category: Linear Guides , Brand: AirTAC , Series: LGC
AirTAC LGC1A40R13-H Cross Roller Guide Specifications
- Model: LGC1A40R13-H
- Type: Precision cross roller linear guide
- Rail width: 40mm (nominal size)
- Carriage quantity per rail: 1 unit (pre-mounted)
- Roller diameter: 3.5mm ±0.002mm
- Dynamic load capacity (C): 12.6kN
- Static load capacity (C0): 24.5kN
- Preload class: Medium (R13 designation)
- Accuracy grade: Normal class (≤50μm/4m)
- Repeat positioning accuracy: ±0.005mm
- Max travel speed: 5m/s
- Sealing: Triple labyrinth seal with grease retention
- Material: Carburized steel SCr420 (rail) / SUJ2 bearings
- Surface hardness: HRC 58-62
- Operating temperature: -20℃ to 100℃
- Weight per meter rail: 4.8kg/m ±2%
- Carriage dimensions: 160mm(L) × 60mm(W) × 40mm(H)
- Mounting hole spacing: 60mm longitudinal pitch
High-rigidity cross roller guide with optimized stress distribution, featuring 45° contact angle rollers arranged in orthogonal pattern. The LGC1A40R13-H combines minimal elastic deformation with vibration damping characteristics, using chrome-plated rails and phosphate coating for corrosion resistance. Requires initial lubrication with ISO VG32-grade grease.
- High-precision CNC grinding machine slides
- Semiconductor wafer handling robots
- Coordinate measuring machine (CMM) axes
- Optical lens polishing equipment
- Lithography stage positioning systems
Installation note:
Achieve ≤0.02mm/m straightness tolerance on mounting surfaces.
Use torque wrench (4.9-5.9N·m for M8 bolts) in crisscross sequence.
Avoid welding sparks exposure within 2m radius.
| Property | Property Value |
|---|---|
| sku | LGC1A40R13-H |
| Roller Outer Diameter | 1.5mm |
| Type | Three-column |
