Airtac LGC Series Cross Roller Guide Rail LGC1A50R13-H
Category: Linear Guides , Brand: AirTAC , Series: LGC
AirTAC LGC1A50R13-H Crossed Roller Guide Specifications
- Model: LGC1A50R13-H
- Type: Precision crossed roller linear guide
- Rail width: 50mm (nominal size)
- Roller diameter: 5.0mm ±0.002mm
- Preload class: R13 (medium preload)
- Accuracy grade: H (high precision)
- Dynamic load capacity (C): 12.5kN
- Static load capacity (C0): 24.8kN
- Moment capacity (MR/MY/Mp): 1,250/1,250/2,480 N·m
- Repeat positioning accuracy: ±0.002mm
- Material: Bearing steel (SUJ2 equivalent) with black oxide coating
- Sealing: Triple labyrinth seal with grease retention
- Temperature range: -20℃ to 100℃ (standard grease)
- Weight per meter: 3.2kg/m ±5%
- Standard lengths: 500-2000mm (customizable)
- Cross-section dimensions: 50mm(W) × 30mm(H) × 50mm(D)
High-rigidity crossed roller guide with optimized stress distribution, featuring V-shaped roller raceways that provide simultaneous load bearing in all directions. The asymmetric roller arrangement enhances moment resistance while maintaining smooth motion characteristics. Includes factory-preloaded rollers for zero-backlash operation.
- High-precision rotary tables in CNC machining centers
- Semiconductor wafer handling robots
- Optical measurement instrument stages
- Medical CT scanner gantry systems
- High-frequency PCB drilling machines
Installation note:
Requires mounting surface flatness ≤0.01mm/m and roughness Ra1.6.
Use torque wrench for rail fastening (recommended torque 22-25N·m).
Apply initial lubrication with ISO VG32 grease in raceways before operation.
| Property | Property Value |
|---|---|
| sku | LGC1A50R13-H |
| Roller Outer Diameter | 1.5mm |
| Type | Three-column |
