Airtac LGC Series Cross Roller Guide Rail LGC1A50R16-H
$135.82
Regular price
$143.32
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
LGC1A50R16-H
Product type:
Collections:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
The LGC Series Cross-Rolled Linear Guide represents a non-recirculating precision motion system characterized by exceptional rigidity and accuracy. This advanced configuration utilizes precisely arranged cross-roller bearings as rolling elements, effectively minimizing friction resistance during operation. The robust rail structure ensures superior load-bearing capacity, making it ideal for heavy-duty applications. Engineered for high-precision requirements, this solution is extensively implemented in precision machinery and measurement equipment, including critical components of PCB drilling machines, optical test systems, X-ray apparatus, and precision optical workstations.
Category: Linear Guides , Brand: AirTAC , Series: LGC
Installation note:
Use 0.02mm/m grade straightedge for alignment. Tighten mounting bolts in crisscross pattern
at 5.5N·m torque. Run-in with 25% speed for initial 10km travel.
Category: Linear Guides , Brand: AirTAC , Series: LGC
AirTAC LGC1A50R16-H Crossed Roller Guide Specifications
- Model: LGC1A50R16-H
- Type: Precision crossed roller linear guide
- Rail width: 50mm
- Roller diameter: 6.35mm (precision ground)
- Preload class: Medium (C2 grade)
- Dynamic load capacity: 22.5kN
- Static load capacity: 38.7kN
- Accuracy grade: P5 (≤5μm/1000mm)
- Max travel speed: 5m/s
- Operating temperature: -10℃ to 80℃
- Material: SUJ2 bearing steel (HRC60+ hardness)
- Sealing: Triple labyrinth seal with grease retention
- Mounting hole pattern: 60mm pitch (M6 threaded)
- Weight: 3.8kg per 500mm length
- Dimensions (per 500mm section):
- Rail: 50mm(W) × 27mm(H)
- Carriage: 68mm(W) × 50mm(H) × 120mm(L)
High-rigidity crossed roller guide with 90° V-groove design for simultaneous load bearing in all directions. Features chrome-plated raceways and vacuum-degassed steel components to minimize micro-vibration. Requires periodic lubrication with ISO VG32-grade grease.
Typical Applications:
- CNC rotary table indexing systems
- Semiconductor wafer inspection stages
- 5-axis machining center trunnion axes
- Optical measurement CMM arms
- High-precision robotic welding positioners
Installation note:
Use 0.02mm/m grade straightedge for alignment. Tighten mounting bolts in crisscross pattern
at 5.5N·m torque. Run-in with 25% speed for initial 10km travel.
| Property | Property Value |
|---|---|
| sku | LGC1A50R16-H |
| Roller Outer Diameter | 1.5mm |
| Type | Three-column |
