Airtac LGC Series Cross Roller Guide Rail LGC1A50R19-H
Category: Linear Guides , Brand: AirTAC , Series: LGC
AirTAC LGC1A50R19-H Crossed Roller Guide Specifications
- Model: LGC1A50R19-H
- Type: Precision crossed roller linear guide
- Rail width: 50 mm
- Roller diameter: 19 mm (G10 precision grade)
- Number of blocks: 1 carriage unit
- Dynamic load capacity (C): 38 kN
- Static load capacity (C0): 78 kN
- Moment capacity (Static):
- Mx: 1,850 Nm
- My: 1,850 Nm
- Mz: 2,450 Nm
- Preload level: Medium (PN3)
- Repeat positioning accuracy: ±3 μm
- Sealing: Double-sided scrapers + end seals (IP54 rated)
- Mounting hole pattern: 60 mm spacing, M6 threaded
- Material:
- Rail/Slider: Chrome alloy steel (HRC 58-62)
- Rollers: SUJ2 bearing steel
- Carriage body: Aluminum alloy (anodized)
- Operating temperature: -15℃ to 80℃
- Weight per 1000mm rail: 5.2 kg
- Dimensions (standard 1000mm unit):
- Length: 1000 mm (customizable)
- Width: 76 mm (including carriage)
- Height: 60 mm
Ultra-precision crossed roller guide system featuring 4-point contact design for equal load distribution. The hardened steel rollers operate at 45° angles to simultaneously handle radial, reverse radial, and lateral loads. Includes pre-loaded configuration for zero-backlash operation, with corrosion-resistant coatings on all critical components.
- High-speed CNC rotary tables (4th/5th axis)
- Semiconductor wafer handling robots
- Optical measuring equipment stages
- Precision grinding machine slides
- Medical CT scanner gantry systems
Installation guidance:
Requires mounting surface flatness ≤0.01mm/m. Use torque wrench (recommended 8-10Nm for M6 bolts)
with sequential tightening pattern. Apply lithium-based grease (NLGI #2) during initial commissioning.
| Property | Property Value |
|---|---|
| sku | LGC1A50R19-H |
| Roller Outer Diameter | 1.5mm |
| Type | Three-column |
