Airtac LGC Series Cross Roller Guide Rail LGC1A60R16-H
Category: Linear Guides , Brand: AirTAC , Series: LGC
AirTAC LGC1A60R16-H Crossed Roller Guide Specifications
- Model: LGC1A60R16-H
- Type: Precision Crossed Roller Linear Guide
- Rail Width: 60 mm
- Roller Diameter: 16 mm (chrome steel)
- Preload Class: Medium preload (C2 grade)
- Dynamic Load Capacity (C): 28.6 kN (radial), 24.8 kN (axial)
- Static Load Capacity (C0): 52.4 kN (radial), 45.3 kN (axial)
- Accuracy Grade: High precision (H class, ±5μm/300mm)
- Material: Carburized steel rail with hardened RC58-62 surface
- Sealing: 4-way labyrinth seal + stainless steel scrapers
- Lubrication: Pre-lubed with ISOVG32 oil, grease nipple included
- Operating Temperature: -15℃ to 80℃
- Protection Rating: IP54 (dust/water resistant)
- Weight per Unit Length: 5.8 kg/m (rail only), 3.2 kg per carriage
- Dimensions (W×H×L):
- Rail: 60mm (width) × 45mm (height) × Custom length (standard 500-2000mm)
- Carriage: 100mm (length) × 76mm (width) × 45mm (height)
Industrial-grade crossed roller guide featuring X-axis/Y-axis integrated load capacity through 90° orthogonal roller arrangement. The hardened V-groove raceway design ensures minimal elastic deformation under complex moment loads. Includes thermal-stabilized alloy components for consistent performance in fluctuating temperatures.
- High-speed CNC rotary tables (4th/5th axis)
- Semiconductor wafer handling robots
- Precision optical alignment stages
- Coordinate measuring machine (CMM) Z-axis
- Medical CT scanner gantry systems
Installation guidelines:1. Use 0.02mm/m grade reference surface for mounting
2. Apply Loctite 243 on mounting screws (M8×1.25)
3. Maintain 0.5-1.5mm clearance between adjacent rails
4. Re-lubricate every 500km travel or 6 months
| Property | Property Value |
|---|---|
| sku | LGC1A60R16-H |
| Roller Outer Diameter | 1.5mm |
| Type | Three-column |
