Airtac LGC Series Cross Roller Guide Rail LGC1A60R19-H
Category: Linear Guides , Brand: AirTAC , Series: LGC
AirTAC LGC Crossed Roller Guide LGC1A60R19-H Technical Specifications
- Model: LGC1A60R19-H
- Type: Crossed roller linear guide with recirculating system
- Rail width: 60mm (standard series)
- Roller diameter: 6.35mm (precision ground)
- Preload level: Medium (H designation)
- Dynamic load capacity (C): 12,500N
- Static load capacity (C0): 24,000N
- Accuracy grade: P5 (≤5μm/m travel deviation)
- Repeat positioning accuracy: ±0.002mm
- Max travel speed: 5m/s
- Operating temperature: -15℃ to 80℃
- Rail material: High-carbon chromium bearing steel (SUJ2 equivalent)
- Surface hardness: HRC 58-62
- Sealing: Triple labyrinth seal with grease retention
- Lubrication: Pre-lubricated with VG68 grease (relubrication ports included)
- Mounting hole pattern: 60mm × 60mm grid (M6 threaded holes)
- Weight per meter: 8.2kg/m
- Standard rail length: 1000mm (customizable up to 4000mm)
- Cross section dimensions: 60mm(W) × 45mm(H)
High-precision crossed roller guide designed for ultra-stable linear motion in critical applications. Features staggered 90° roller arrangement for equal load distribution in all directions. The R19 suffix indicates enhanced corrosion resistance with special surface treatment (nickel-phosphorus plating). Includes integrated wipers to prevent particulate ingress.
- Semiconductor wafer handling robots
- Medical CT scanner gantry systems
- Precision coordinate measuring machines (CMM)
- Lithography equipment stages
- High-speed CNC tool changers
Installation note:
Requires mounting surface flatness ≤0.01mm/m and parallelism ≤0.02mm between rails.
Use torque wrench (4.9-5.9N·m for M6 bolts) in diagonal tightening sequence.
Avoid welding near installed rails due to thermal distortion risks.
| Property | Property Value |
|---|---|
| sku | LGC1A60R19-H |
| Roller Outer Diameter | 1.5mm |
| Type | Three-column |
